Allen-Bradley 1769-IQ32T Input Module

Series#: AllenBradley

Product Details

Model 1769-IQ32T – High-density 32-point 24V DC sinking input module for Allen-Bradley CompactLogix systems.
32 discrete input channels in a compact form factor, saving panel space and reducing wiring complexity.
Supports 24V DC sinking inputs with built-in LED indicators for quick diagnostics and troubleshooting.
Removable terminal block (RTB) design for easy installation, maintenance, and field wiring changes.
Seamless integration with 1769 Compact I/O backplane – hot-swappable and fully compatible with 1769 bus.
Rugged industrial construction with wide operating temperature range (-20°C to +60°C) for harsh environments.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Allen-Bradley 1769-IQ32T is a high-performance 32-point DC sinking input module designed for the CompactLogix platform, offering exceptional density and reliability for discrete signal acquisition in automated manufacturing, process control, and machine builder applications. This module features 32 individually isolated input channels, each accepting 24V DC signals, and is engineered to provide fast response times with minimal power consumption. The 1769-IQ32T utilizes a removable terminal block for simplified wiring and maintenance, and its compact footprint allows for maximum I/O density in space-constrained cabinets. With robust electrical isolation and surge protection, it ensures stable operation in electrically noisy industrial environments. Below is the detailed technical specification table for the 1769-IQ32T module.

Parameter	Specification (1769-IQ32T)
Module Type	Discrete DC Input Module
Number of Inputs	32 (sinking)
Input Voltage Range	10-30V DC (rated 24V DC)
Input Current (per point)	6 mA at 24V DC typical
Input Filter Time	0.5 ms to 32 ms (software selectable)
Off-State Voltage	Max 5V DC
On-State Voltage	Min 10V DC
Input Impedance	4.0 kΩ typical
Isolation Voltage	1000V AC for 1 second (between field and backplane)
Backplane Current Consumption	5V DC: 80 mA typical; 24V DC: 0 mA
Power Dissipation	2.5 W typical (all inputs on)
Operating Temperature	-20°C to +60°C (-4°F to +140°F)
Storage Temperature	-40°C to +85°C (-40°F to +185°F)
Relative Humidity	5% to 95% non-condensing
Vibration Resistance	5 g Standard Models 10-500 Hz
Shock Resistance	30 g peak
Terminal Type	Removable terminal block (RTB), 36-pin
Wire Size	0.5 to 1.5 mm² (22-14 AWG)
Indicators	Green LED per input for channel status
Module Location	CompactLogix 1769 I/O backplane
Keying	Mechanical keying with removable key pins
Weight	Approx. 0.14 kg (0.31 lb)
Certifications	UL, CE, C-Tick, RoHS compliant
