Mitsubishi GT2107-WTBD Touch Screen HMI

Series#: Mitsubishi

Product Details

Model: 7″ Mitsubishi Touch screen HMIs GT2107-WTBD – High-performance operator interface for industrial automation.
Features a 7.0-inch TFT color LCD display with 800 x 480 resolution for clear, vibrant visualization.
Powered by 24VDC with low power consumption (11.3W max load) and robust electrical protection.
Compact black frame design with wide operating temperature range and noise resistance for harsh environments.
Supports seamless integration with Mitsubishi PLCs and other automation systems via standard communication ports.
Fast global shipping available – order now for quick delivery.

Specification

The 7″ Mitsubishi Touch screen HMIs GT2107-WTBD is a state-of-the-art graphical operator terminal engineered for demanding industrial control applications. This model delivers a crisp 7-inch TFT color LCD display with 800 x 480 pixel resolution, ensuring operators have clear, real-time data visualization. Built with a robust 24VDC power input and featuring an inrush current of 35A or less (3ms at 25°C under maximum load), it offers reliable performance in factory floor environments. With a power consumption of only 11.3W at maximum load and 7.0W with backlight off, it is energy-efficient without compromising functionality. The GT2107-WTBD is designed to withstand noise interference (1000Vp-p, 1μs width, 30-100Hz) and provides insulation resistance of 10MΩ or more (500VDC across power supply terminals and earth). Its black frame and compact footprint make it ideal for panel mounting in space-constrained setups.

Specification	Value
Model	GT2107-WTBD
Display Size	7.0 inches
Resolution	800 x 480 dots
Display Type	TFT color LCD
Frame Color	Black
Power Supply Voltage	24VDC (+10%, -15%)
Power Consumption (Max Load)	11.3W or less
Power Consumption (Backlight Off)	7.0W
Inrush Current	35A or less (3ms, 25°C, max load)
Permissible Instantaneous Failure Time	Within 5ms
Noise Resistance	1000Vp-p, 1μs width, 30-100Hz
Withstand Voltage	500VAC for 1 minute (power to ground)
Insulation Resistance	10MΩ or more at 500VDC

Display Performance: 800 x 480 resolution on a 7.0-inch TFT color LCD ensures high-contrast, readable graphics even in bright factory lighting.
Power Management: 24VDC input with a maximum load of 11.3W and standby mode of 7.0W optimizes energy use in continuous operation.
Electrical Protection: Inrush current limited to 35A (3ms) prevents circuit damage; withstand voltage of 500VAC and insulation resistance >10MΩ ensure safety.
Environmental Tolerance: Noise resistance up to 1000Vp-p and permissible failure time within 5ms guarantee stable operation in electrically noisy environments.
Physical Design: Black frame and compact 7-inch form factor allow easy integration into existing control panels.
