The GT2512-STBA and GT2512-STBD are premium 12.1-inch Mitsubishi GOT2000 series touch screen HMIs, engineered for demanding industrial control applications. These units deliver exceptional visualization and control capabilities with a bright, high-resolution display and a comprehensive suite of built-in interfaces, ensuring seamless integration into existing automation architectures. Their rugged construction and long-life components guarantee sustained performance in continuous operation environments.
| Parameter |
Specification |
| Display Type |
TFT Color LCD |
| Screen Size |
12.1" |
| Resolution (Dots) |
800 x 600 (SVGA) |
| Display Size (W x H) mm |
246 x 184.5 |
| Display Colors |
65536 Colors |
| Intensity Adjustment |
32-Level |
| Backlight Type |
LED (non-replaceable) |
| Backlight Life |
Approx. 60,000 hours or more |
| Touch Panel Type |
Analog Resistive Film |
| Touch Panel Life |
1 million times or more |
| Panel Color |
Black (BA/BD) / White (NA/ND) |
| User Memory |
ROM: 32MB, RAM: 80MB |
| Internal Clock Accuracy |
±90 sec/month (at 25°C) |
| Battery Type |
GT11-50BAT Lithium |
| Battery Life |
Approx. 5 years (at 25°C) |
| RS-232 |
1ch, D-sub 9-pin (male) |
| RS-422/485 |
1ch, D-sub 9-pin (female) |
| Ethernet |
1ch, 10BASE-T/100BASE-TX, RJ-45 |
| USB (Host) |
2 channels, USB-A, High-Speed 480Mbps |
| USB (Device) |
1 channel, USB Mini-B, High-Speed 480Mbps |
| SD Card Slot |
1ch, SDHC compliant (max. 32GB) |
| Protective Construction |
Front: IP67F, Panel interior: IP2X |
| External Dimensions (WxHxD) mm |
316 x 246 x 52 (BA/BD) / 311 x 237 x 54 (NA/ND) |
| Panel Cutout (WxH) mm |
302 x 228 (BA/BD) / 269 x 214 (NA/ND) |
| Weight (kg) |
2.4 |
| Application Software |
GT Works3 V1.112S or later |
- Display & Visuals: The 12.1-inch SVGA TFT LCD delivers 800x600 resolution with 65536 colors, providing exceptional clarity for complex process graphics and data visualization. The 32-level intensity adjustment ensures optimal readability under varying ambient light conditions.
- Touch & Interaction: Analog resistive film touch panel supports up to 2 simultaneous touch points, with a minimum key size of 2x2 dots. The touch panel is rated for over 1 million operations, ensuring long-term reliability in high-use applications.
- Memory & Processing: Equipped with 32MB ROM for project storage and 80MB RAM for runtime operations, the GT2512 series can handle large-scale HMI applications with complex animations, alarms, and data logging.
- Connectivity & Expansion: Built-in RS-232 and RS-422/485 serial ports enable direct connection to PLCs and drives. 10BASE-T/100BASE-TX Ethernet facilitates high-speed data exchange and remote monitoring. Dual USB-A host ports and one USB Mini-B device port support data transfer, firmware updates, and peripheral connectivity. An SDHC card slot accepts up to 32GB for additional data storage.
- Durability & Environment: The front panel is rated IP67F, offering robust protection against dust and water ingress, making it suitable for washdown and outdoor environments. The LED backlight has a lifespan of over 60,000 hours, significantly reducing maintenance intervals.
- Power & Indicators: Features a dual-color power LED (blue/orange) for clear status indication. A single-tone buzzer with adjustable frequency and duration provides audible feedback for alarms and operator prompts.
