The GT2107-WTSD is a premium 7-inch Mitsubishi touch screen HMI engineered for demanding industrial environments. This model combines a vivid TFT color LCD with an 800 x 480 pixel resolution, ensuring clear data visualization and intuitive operator interaction. Designed for seamless integration into control systems, the GT2107-WTSD operates on a standard 24VDC supply and features a silver frame for enhanced aesthetics. Its robust electrical specifications, including high noise immunity and insulation resistance, guarantee stable operation even in electrically noisy settings. Backed by rigorous quality assurance, this unit is a reliable choice for OEMs and system integrators seeking a high-performance HMI solution.
| Parameter |
Specification |
| Screen Size |
7.0″ |
| Resolution |
800 x 480 dots |
| Display Type |
TFT color LCD |
| Frame Color |
Silver |
| Power Supply Voltage |
24VDC (+10%, -15%) |
| Power Consumption (Max Load) |
11.3W or less |
| Power Consumption (Backlight Off) |
7.0W |
| Inrush Current |
35A or less (3ms, 25°C, max load) |
| Permissible Instantaneous Failure Time |
Within 5ms |
| Noise Resistance |
1000Vp-p, 1μs, 30-100Hz |
| Withstand Voltage |
500VAC for 1 minute (power to ground) |
| Insulation Resistance |
10MΩ or more at 500VDC |
Additional Technical Insights:
- Power Supply: Wide input tolerance (24VDC ±15%) ensures stability under voltage fluctuations.
- Electromagnetic Compatibility: High noise resistance (1000Vp-p) prevents false triggers in industrial environments.
- Thermal Management: Low power dissipation (11.3W max) reduces heat buildup, extending component life.
- Installation: Silver frame design allows easy panel mounting with standard cutouts.
- Reliability: Insulation resistance ≥10MΩ at 500VDC ensures safe isolation from ground faults.
