Mitsubishi GT2310-VTBA Touch Panel HMI

Series#: Mitsubishi

Product Details

Model: MITSUBISHI GT2310-VTBA GOT2000 Series HMI Touch Panel
10.4-inch TFT LCD display with 65,536 colors for vivid, high-resolution visualization
Integrated Ethernet, RS-232, RS-422/485, and SD memory card slot for flexible connectivity
IP67F front panel protection for harsh industrial environments
Compact design: 303mm (W) x 218mm (H) x 56mm (D), lightweight at 1.9 kg
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

The MITSUBISHI GT2310-VTBA is a high-performance HMI from the GOT2000 Series, designed to deliver intuitive machine control and monitoring in demanding industrial settings. With its 10.4-inch TFT display and 1024x648 pixel resolution, this touch panel offers exceptional clarity and touch responsiveness, enabling efficient operator interaction. Supporting multiple communication protocols including MODBUS, Ethernet, and CC-Link, the GT2310-VTBA seamlessly integrates into existing automation architectures. Its robust IP67F front protection ensures reliable operation in dusty or wet conditions, while the AC power supply (100-240 V) simplifies installation across global facilities. This model is ideal for applications requiring a compact yet powerful interface with built-in USB and SD storage capabilities.

Specification	Details
Series	GOT2000 Series
Model	GT2310-VTBA
Display Type	TFT Color LCD
Display Colors	65,536
Display Size	10.4 inches
Resolution	1024 x 648 pixels
Power Supply Voltage	100-240 V AC
Protection Class	IP67F (front panel only)
Internal Memory	9 MB
Memory Card Slot	SD
USB Ports	2
Ethernet Port	1
RS-232 Port	1
RS-422/485 Port	1
Network Options	MODBUS, Ethernet, CC-Link
Depth	56 mm
Width	303 mm
Height	218 mm
Weight	1.9 kg
CE Compliance	Compliant
Shipping Approvals	Non-compliant
EAC Compliance	Compliant
UL/cUL Compliance	Compliant
UKCA Compliance	Compliant
