Mitsubishi GT2510F-VTNA Touch Screen HMI

Series#: Mitsubishi

Product Details

【10.4″ Mitsubishi Touch screen HMIs GT2510F-VTNA】 – High-performance GOT2000 series HMI for advanced industrial automation.
10.4-inch TFT color LCD with 800x600 SVGA resolution for crisp, clear visuals.
Analog resistive touch panel with 1 million+ operation life and 32-level intensity adjustment.
Robust connectivity: RS-232, RS-422/485, Ethernet, USB Host/Device, and SDHC slot.
IP67F front protection and IP2X rear rating for harsh industrial environments.
Compact design with 303x218x52mm dimensions and lightweight 2.1kg construction.
Guaranteed 100% Original factory condition, offering fast and secure worldwide delivery.

Specification

The Mitsubishi GT2510F-VTNA is a cutting-edge 10.4-inch operator interface from the GOT2000 series, engineered for demanding industrial control and visualization tasks. This model combines a bright, 65536-color TFT LCD with a responsive analog resistive touch panel, ensuring reliable operation in factory floor conditions. With its comprehensive interface suite including dual USB ports, Ethernet, and serial communication, the GT2510F-VTNA seamlessly integrates into existing Mitsubishi PLC networks or third-party systems, offering unparalleled flexibility for machine builders and system integrators.

Parameter	Specification
Display Type	TFT Color LCD
Screen Size	10.4″
Resolution	800 x 600 (SVGA)
Display Colors	65,536 Colors
Intensity Adjustment	32-level
Backlight Type	LED (Non-replaceable)
Backlight Life	Approx. 60,000 hours (to 50% brightness at 25°C)
Touch Panel Type	Analog Resistive Film
Touch Life	1 million+ operations (0.98N or less)
User Memory	ROM: 32MB, RAM: 80MB
Battery	GT11-50BAT Lithium (approx. 5 years life at 25°C)
Internal Clock Accuracy	±90 sec/month (at 25°C)
Protection Rating	Front: IP67F, Rear (panel): IP2X
External Dimensions (WxHxD)	303 x 218 x 52 mm
Weight	2.1 kg (excluding mounting brackets)

Serial Interfaces: 1x RS-232 (D-sub 9-pin male) and 1x RS-422/485 (D-sub 9-pin female) with speeds up to 115200 bps.
Ethernet: 1x 10BASE-T/100BASE-TX (RJ-45) for high-speed network communication.
USB Host: 2x USB-A ports (High-Speed 480Mbps) for connecting peripherals like keyboards or storage.
USB Device: 1x USB Mini-B (High-Speed 480Mbps) for PC connection and data transfer.
SD Card Slot: 1x SDHC compliant slot supporting up to 32GB for data logging and firmware updates.
Extension Interface: For communication or option unit mounting (e.g., LAN or grip switch).
Sound & Buzzer: Single tone buzzer (adjustable tone/length) with optional 3.5mm audio output.
Power LED: Bi-color (blue/orange) for status indication.
Software Compatibility: GT Works3 version 1.112S or later (GOT2000 series).
