The Mitsubishi GT2508-VTWA is a compact yet powerful 8.4-inch HMI that delivers reliable performance for mid-range automation tasks. This model features a 640x480 VGA TFT color LCD with 65,536 colors, providing excellent readability. With its IP67F-rated front bezel, the GT2508-VTWA is built to withstand dust and water ingress, making it ideal for demanding industrial settings. It supports a wide range of communication protocols and offers ample memory (32MB ROM + 80MB RAM) for complex screen designs.
| Parameter |
Specification |
| Model |
GT2508-VTWA |
| Display Type |
TFT Color LCD |
| Screen Size |
8.4″ |
| Resolution |
640 x 480 (VGA) |
| Display Size (W x H) |
170.9 x 128.2 mm |
| Display Colors |
65,536 Colors |
| Backlight |
LED (Not replaceable) |
| Backlight Life |
Approx. 60,000 hours (at 25°C) |
| Touch Panel |
Analog Resistive Film |
| Touch Life |
1 million times or more |
| Memory (ROM/RAM) |
32 MB / 80 MB |
| Panel Color |
White |
| Protection |
Front: IP67F, Rear: IP2X |
| External Dimensions |
241 x 194 x 51 mm (W x H x D) |
| Panel Cutout |
227 x 176 mm |
| Weight |
1.5 kg (without brackets) |
| Battery |
GT11-50BAT Lithium (5-year life) |
| Application Software |
GT Designer3 Version 1.112S |
Interface & Connectivity:
- RS-232: 1 channel, D-sub 9-pin (male), speeds up to 115200 bps.
- RS-422/485: 1 channel, D-sub 9-pin (female), speeds up to 115200 bps.
- Ethernet: 1 channel, 10BASE-T/100BASE-TX, RJ-45 connector.
- USB (Host): 1 rear port (USB-A), High-Speed 480 Mbps.
- USB (Device): 1 rear port (USB Mini-B), High-Speed 480 Mbps.
- SD Card: 1 slot, SDHC compliant (up to 32 GB).
- Extension Interface: For communication/option units.
- Sound Output: f3.5 mm jack.
- Buzzer: Single tone, adjustable.
- Power LED: 2 colors (blue, orange).
Operational & Environmental:
- Internal Clock Accuracy: ±90 sec/month (at 25°C).
- Intensity Adjustment: 32-level adjustment.
- Key Size: Minimum 2x2 dots per key.
- Simultaneous Press: Maximum 2 points.
- Memory Life: 100,000 write cycles.
