The 8.4″ Mitsubishi Touch Screen HMIs GT2508-VTWD is a compact yet powerful operator interface from the GOT2000 series, engineered for demanding automation tasks. Featuring a bright 8.4-inch TFT color LCD with 640x480 VGA resolution, this unit delivers sharp graphics and responsive touch control. Its rugged design includes an IP67F-rated front bezel and a high-durability analog resistive touch panel, making it suitable for wet, dusty, or vibration-prone environments. With built-in Ethernet, multiple serial interfaces, USB host/device ports, and an SD card slot, the GT2508-VTWD offers flexible connectivity for PLCs, drives, and other field devices. It is backed by 32MB of ROM and 80MB of RAM for smooth operation of complex HMI applications, and its LED backlight ensures long service life with minimal maintenance.
| Parameter |
Specification (GT2508-VTWD) |
| Display Type |
TFT Color LCD |
| Screen Size |
8.4″ |
| Resolution |
640 x 480 (VGA) |
| Display Size (W x H) mm |
170.9 x 128.2 |
| Number of Characters |
16-dot: 50 chars x 30 lines / 12-dot: 53 chars x 40 lines |
| Display Colors |
65536 Colors |
| Intensity Adjustment |
32-Level |
| Backlight Type |
LED (non-replaceable) |
| Backlight Life |
Approx. 60,000 hours or more (to 50% brightness at 25°C) |
| Touch Panel Type |
Analog Resistive Film |
| Key Size |
Minimum 2 x 2 dots |
| Simultaneous Press |
Maximum 2 points |
| Touch Life |
1 million times or more (at 0.98N force) |
| Panel Color |
White (as per suffix -WD) |
| User Memory |
ROM: 32MB, RAM: 80MB |
| Memory Life (Writes) |
100,000 times |
| Internal Clock Accuracy |
±90 sec/month (at 25°C) |
| Battery Type |
GT11-50BAT Lithium Battery |
| Battery Life |
Approx. 5 years (at 25°C) |
| RS-232 Interface |
1ch, D-sub 9-pin (male), up to 115200 bps |
| RS-422/485 Interface |
1ch, D-sub 9-pin (female), up to 115200 bps |
| Ethernet Interface |
1ch, 10BASE-T/100BASE-TX, RJ-45 |
| USB (Host) |
1 port (rear), USB-A, High-Speed 480Mbps |
| USB (Device) |
1 port (rear), USB Mini-B, High-Speed 480Mbps |
| SD Card Slot |
1ch, SDHC compliant (max 32GB) |
| Extension Interface |
For communication/option unit mounting |
| Auxiliary Extension I/F |
For option unit mounting |
| Side Interface |
For LAN communication unit mounting |
| Sound Output Interface |
Not provided on this model |
| Buzzer Output |
Single tone (adjustable tone/length) |
| Power LED |
2 colors (blue, orange) |
| Protective Construction |
Front: IP67F, Rear panel: IP2X |
| External Dimensions (WxHxD) mm |
241 x 194 x 51 |
| Panel Cutout (WxH) mm |
227 x 176 |
| Weight (kg) |
1.5 (excluding mounting brackets) |
| Application Software Package |
GT Works3 Version 1.112S or later |
- Power Supply: 24V DC (typical consumption 14W or less) – reliable for industrial control cabinets.
- Operating Temperature: 0 to 55°C (32 to 131°F) – suitable for factory floor environments.
- Storage Temperature: -20 to 60°C (-4 to 140°F) – robust for shipping and storage.
- Vibration Resistance: Compliant with JIS B 3502, IEC 61131-2 – withstands industrial vibration.
- Shock Resistance: 147 m/s² (15 G) for 11 ms – durable against accidental impacts.
- Certifications: CE, UL/cUL, and RoHS compliant – meets global safety and environmental standards.
