Mitsubishi GT2508F-VTNA Touch Screen HMI

Series#: Mitsubishi

Product Details

Model: 8.4" Mitsubishi Touch Screen HMI GT2508F-VTNA – Compact and powerful operator interface for demanding industrial environments.
Features a high-resolution 640 x 480 VGA TFT Color LCD display with 65,536 colors for crisp, clear visualization.
Robust 32MB ROM / 80MB RAM memory ensures fast screen transitions and ample data logging capacity.
Equipped with Ethernet (10BASE-T/100BASE-TX), RS-232, and RS-422/485 interfaces for flexible connectivity.
Durable IP67F front panel protection (when mounted) for resistance against dust and water ingress.
Integrated SDHC card slot (up to 32GB) and dual USB ports for easy data transfer and firmware updates.
Guaranteed 100% Original factory condition, offering fast and secure worldwide delivery.

Specification

The 8.4" Mitsubishi Touch Screen HMI GT2508F-VTNA is a high-performance operator interface designed for seamless integration into advanced automation systems. This GOT2000 series unit delivers reliable operation with a vivid 8.4-inch TFT color LCD display, offering 640 x 480 VGA resolution and 65,536 colors for excellent readability. With its robust memory architecture (32MB ROM / 80MB RAM), the GT2508F-VTNA handles complex screen data and historical trends effortlessly. Its comprehensive communication suite—including Ethernet, RS-232, RS-422/485, and USB—enables direct connection to PLCs, drives, and other field devices. Built for harsh environments, the unit features an IP67F-rated front panel and a long-life LED backlight rated for approximately 60,000 hours. This model is 100% original and new, backed by fast global shipping from stock.

Key Technical Specifications
Display Type	TFT Color LCD
Screen Size	8.4 inches
Resolution	640 x 480 (VGA)
Display Size (W x H)	170.9 x 128.2 mm
Display Colors	65,536 colors
Backlight	LED (non-replaceable)
Backlight Life	Approx. 60,000 hours (to 50% brightness at 25°C)
Touch Panel	Analog Resistive Film (2-point simultaneous press)
Touch Panel Life	1 million+ operations (0.98N or less)
Memory (User)	ROM: 32MB / RAM: 80MB
Battery	GT11-50BAT Lithium (approx. 5 years life at 25°C)
Internal Clock Accuracy	±90 seconds/month (at 25°C)
Ethernet	1 ch, 10BASE-T/100BASE-TX, RJ-45
RS-232	1 ch, D-sub 9-pin (male)
RS-422/485	1 ch, D-sub 9-pin (female)
USB (Host)	1 ch (rear), USB-A, High-Speed 480Mbps
USB (Device)	1 ch (rear), USB Mini-B, High-Speed 480Mbps
SD Card Slot	1 ch, SDHC compliant (max 32GB)
Protection Rating	Front: IP67F (when mounted), Panel: IP2X
External Dimensions (W x H x D)	241 x 194 x 51 mm
Panel Cutout (W x H)	227 x 176 mm
Weight	1.5 kg (excluding mounting brackets)

Software Compatibility: Works with GT Works3 (version 1.112S or later) for full configuration and monitoring.
Built-in Interfaces: Includes sound output (buzzer, single tone adjustable) and power LED (blue/orange) for status indication.
Extension Options: Supports communication/option units via dedicated expansion interface and side interface for LAN modules.
Environmental Resilience: Designed for operation in temperatures from 0°C to 55°C and storage from -20°C to 60°C.
Reliable Power Supply: Accepts 24V DC input (typical consumption 10W or less) for low-energy operation.
