The 7″ Mitsubishi Touch screen HMIs GT2507-WTBD is a state-of-the-art graphical operator terminal from the GOT2000 series, engineered for superior performance and reliability in factory automation. This model features a 7-inch, high-brightness TFT color LCD with 800×480 pixel resolution, providing exceptional clarity for data monitoring and control. With a 65536-color display and 32-level intensity adjustment, operators benefit from excellent readability even in challenging lighting conditions. The unit is equipped with a durable analog resistive touch panel supporting up to 2 simultaneous presses, rated for over 1 million actuations. Its front panel meets IP67F standards, ensuring protection against dust and water ingress, while the internal IP2X rating safeguards the backside when panel-mounted. The GT2507-WTBD comes with a comprehensive set of built-in interfaces, including RS-232, RS-422/485, and a 10BASE-T/100BASE-TX Ethernet port for seamless PLC and network communication. Dual USB ports (Host: USB-A for peripherals, Device: USB Mini-B for programming) and an SDHC card slot (up to 32GB) provide flexible data logging and firmware upgrade options. Powered by a 32MB ROM and 80MB RAM architecture, this HMI handles complex screen transitions and animations with ease. An internal real-time clock (±90 sec/month accuracy) and a GT11-50BAT lithium battery (approx. 5-year life) ensure reliable time-stamping and data retention. The unit also features a multi-tone buzzer and a bi-color (blue/orange) power LED for status indication. All these attributes make the GT2507-WTBD a premier choice for OEMs and system integrators requiring a compact, rugged, and highly capable touch screen HMI.
| Specification |
Detail |
| Model |
GT2507-WTBD |
| Display Type |
TFT Color LCD |
| Screen Size |
7.0 inches |
| Resolution |
800 × 480 dots (WVGA) |
| Display Size (W x H) |
152.4 × 91.4 mm |
| Display Colors |
65536 colors |
| Intensity Adjustment |
32-level adjustment |
| Backlight Type |
LED (not replaceable) |
| Backlight Life |
Approx. 60,000 hours or more (to 50% intensity at 25°C) |
| Touch Panel Type |
Analog Resistive Film |
| Touch Panel Life |
1 million times or more (≤0.98N force) |
| Simultaneous Press |
Maximum 2 points |
| Panel Color |
Black/Silver (B/S) |
| User Memory |
ROM: 32MB / RAM: 80MB |
| Internal Clock Accuracy |
±90 seconds/month (at 25°C) |
| Battery Type |
GT11-50BAT Lithium Battery |
| Battery Life |
Approx. 5 years (at 25°C) |
| RS-232 Interface |
1ch, D-sub 9-pin (male), 115200/57600/38400/19200/9600/4800 bps |
| RS-422/485 Interface |
1ch, D-sub 9-pin (female), 115200/57600/38400/19200/9600/4800 bps |
| Ethernet Interface |
1ch, 10BASE-T/100BASE-TX, RJ-45 connector |
| USB (Host) |
1ch (rear), USB-A, High-Speed 480 Mbps |
| USB (Device) |
1ch (rear), USB Mini-B, High-Speed 480 Mbps |
| SD Card Slot |
1ch, SDHC compliant (max. 32GB) |
| Protective Construction |
Front: IP67F / In control panel: IP2X |
| External Dimensions (W×H×D) |
214 × 158 × 55 mm |
| Panel Cutout (W×H) |
197 × 141 mm |
| Weight (excl. brackets) |
1.2 kg |
| Application Software |
GT Designer3 Version 1.175H or later |
- Buzzer Output: Single tone, with adjustable tone and length.
- Power LED: Bi-color (blue/orange) for status indication.
- Extension Interface: For communication unit or optional unit mounting (e.g., grip switch, stop switch).
- Side Interface: For LAN communication unit mounting.
- Sound Output Interface: 3.5 mm audio jack for external speakers.
- Human Sensor: Detection distance up to 1 m with a temperature differential of ≥4°C.
- Memory Life: Rated for 100,000 write cycles for user memory.
- Key Size: Minimum 2×2 dots per key for touch input.
