The 7″ Mitsubishi Touch screen HMIs GT2507-WTSD is a robust and feature-rich operator interface from the renowned GOT2000 series, designed to meet the demanding needs of modern industrial control systems. This 7-inch model delivers exceptional performance with its high-resolution TFT color LCD, extensive connectivity options, and rugged construction, making it ideal for factory automation, process control, and machine monitoring applications. With a compact footprint and IP67F front protection, the GT2507-WTSD ensures reliable operation even in challenging environments, offering engineers a versatile and long-lasting HMI solution.
| Parameter |
Specification (GT2507-WTSD) |
| Display Type |
TFT Color LCD |
| Screen Size |
7.0 inches |
| Resolution (Dots) |
800 x 480 (WVGA) |
| Display Size (W x H) mm |
152.4 x 91.4 mm |
| Number of Characters |
16-dot: 50 chars. x 30 lines; 12-dot: 66 chars. x 40 lines (2-byte) |
| Display Colors |
65,536 colors |
| Intensity Adjustment |
32-level adjustment |
| Backlight Type |
LED (not replaceable) |
| Backlight Life |
Approx. 60,000 hours or more (at 25°C ambient, to 50% brightness) |
| Touch Panel Type |
Analog Resistive Film |
| Touch Panel Life |
1 million times or more (operating force ≤ 0.98N) |
| Panel Color |
Black/Silver (B/S) |
| Memory User Memory Capacity |
ROM: 32MB, RAM: 80MB |
| Internal Clock Accuracy |
±90 seconds/month (at 25°C) |
| Battery Type |
GT11-50BAT lithium battery (life approx. 5 years at 25°C) |
| RS-232 |
1ch, D-sub 9-pin (male), speeds up to 115200 bps |
| RS-422/485 |
1ch, D-sub 9-pin (female), speeds up to 115200 bps |
| Ethernet |
1ch, 10BASE-T/100BASE-TX, RJ-45 |
| USB (Host) |
2 channels (front/rear), High-Speed 480Mbps, USB-A connector |
| USB (Device) |
1 channel (front), High-Speed 480Mbps, USB Mini-B connector |
| SD Card |
1ch, SDHC compliant (max 32GB) |
| Extension Interface |
For communication/option unit mounting |
| Auxiliary Extension I/F |
For option unit mounting |
| Side Interface |
For LAN communication unit mounting |
| Sound Output Interface |
3.5mm jack (on select models) |
| Buzzer Output |
Single tone (tone and length adjustable) |
| Power LED |
2 colors (blue, orange) |
| Protective Construction |
Front: IP67F (*6, *9 or *7, *9); In control panel: IP2X |
| External Dimensions (W x H x D) mm |
214 x 158 x 55 mm |
| Panel Cutout (W x H) mm |
197 x 141 mm |
| Weight (kg) |
0.75 kg (excluding mounting brackets) |
| Application Software Package |
GT Works3 Version 1.175H or later |
- Connectivity: Built-in serial (RS-232/422/485), Ethernet, and dual USB ports enable seamless integration with PLCs, drives, and other automation devices.
- Environmental Resilience: The IP67F front panel ensures protection against dust and water ingress, while the IP2X rear safeguards internal components.
- Long-Lasting Components: The LED backlight offers over 60,000 hours of reliable operation, and the touch panel withstands up to 1 million presses for extended service life.
- Memory and Performance: With 32MB of ROM and 80MB of RAM, the GT2507-WTSD handles complex screens and data logging tasks efficiently.
- Expandability: Supports SDHC cards up to 32GB for data storage and firmware updates, plus optional communication/extension units via dedicated slots.
- Software Compatibility: Fully supported by GT Works3 (Version 1.175H or later) for intuitive screen design and project management.
- Global Shipping: All units are 100% original, factory-sealed, and shipped from stock with fast, reliable delivery worldwide.
