Mitsubishi GT2507T-WTSD Touch Screen HMI

Series#: Mitsubishi

Product Details

Model: 7″ Mitsubishi Touch screen HMIs GT2507T-WTSD – The perfect balance of size and performance for demanding industrial HMI applications.
High-Resolution 7″ TFT Color LCD: Delivers crisp, clear visuals with 800 x 480 dots resolution, ensuring excellent readability for complex process data.
Robust Connectivity: Equipped with built-in RS-232, RS-422/485, Ethernet (10BASE-T/100BASE-TX), and dual USB ports for seamless integration into any automation network.
Durability & Reliability: Features an IP67F front panel protection rating, LED backlight with >60,000 hours life, and a resistive touch panel rated for over 1 million presses.
Expandable Memory: Offers 32MB ROM and 128MB RAM user memory, supporting complex screen projects and data logging via SDHC card (up to 32GB).
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

The 7″ Mitsubishi Touch screen HMIs GT2507T-WTSD represents a highly optimized Human-Machine Interface solution, specifically engineered for mid-range automation tasks where space is at a premium but performance cannot be compromised. This model, part of the renowned GOT2000 series, integrates a vivid 7-inch TFT color LCD with a wide 800x480 resolution, providing operators with an intuitive and responsive control surface. Its rugged construction, featuring an IP67F front bezel and a durable analog resistive touch panel, ensures reliable operation even in harsh industrial environments. The GT2507T-WTSD is not just a display; it is a powerful control hub equipped with versatile communication interfaces including Ethernet, serial ports, and high-speed USB, making it an ideal choice for machine builders and system integrators seeking a cost-effective yet feature-rich operator terminal.

Product Attribute	Specification (GT2507T-WTSD)
Display Type	TFT Color LCD
Screen Size	7.0 inches
Resolution (Dots)	800 x 480 (WVGA)
Display Size (W x H) mm	152.4 x 91.4
Display Colors	65536 Colors
Backlight Type	LED (Non-replaceable)
Backlight Life	Approx. 60,000 hours or more (to 50% intensity at 25°C)
Touch Panel Type	Analog Resistive Film
Touch Panel Life	1 Million times or more (0.98N or less)
User Memory Capacity	ROM: 32MB, RAM: 128MB
Internal Clock Accuracy	±90 sec/month (at 25°C)
Battery Life	Approx. 5 years (at 25°C)
Built-in Interface RS-232	1ch, D-sub 9-pin (male), up to 115200 bps
Built-in Interface RS-422/485	1ch, D-sub 9-pin (female), up to 115200 bps
Ethernet Interface	1ch, 10BASE-T/100BASE-TX, RJ-45
USB (Host)	2 channels (USB-A), High-Speed 480Mbps
USB (Device)	1 channel (USB Mini-B), High-Speed 480Mbps
SD Card Slot	1ch, SDHC compliant (max. 32GB)
Protective Construction	Front: IP67F, Control Panel: IP2X
External Dimensions (W x H x D) mm	214 x 158 x 55
Panel Cutout (W x H) mm	197 x 141
Weight (excl. brackets) kg	1.2

Intensity Adjustment: 32-level adjustment for optimal readability in varying ambient light conditions.
Simultaneous Touch Points: Maximum 2 points, allowing for basic multi-touch gestures.
Buzzer Output: Single tone with adjustable frequency and length for audible feedback.
Power LED: Dual-color indicator (blue/orange) for clear operational status.
Battery Type: GT11-50BAT lithium battery for real-time clock backup.
Memory Life: 100,000 write cycles for reliable long-term data storage.
Application Software Package: Compatible with GT Works3 version 1.175H or later for full project development.
