The Mitsubishi GT2505HS-VTBD is a high-performance handheld HMI from the GOT2000 series, engineered for on-the-go machine operation and diagnostics. Featuring a 5.7-inch VGA TFT color LCD with 65,536 colors and a durable analog resistive touch panel supporting up to 2 simultaneous presses, this unit delivers crisp visualization and responsive control. The built-in human sensor detects operator presence within 1 meter, while the front panel meets IP67F standards, ensuring reliable performance in harsh environments. With versatile connectivity including RS-232, RS-422/485, Ethernet, dual USB interfaces, and an SDHC card slot, the GT2505HS-VTBD integrates seamlessly into existing automation networks. The ergonomic grip design, combined with a lightweight 0.6 kg body, makes it ideal for mobile troubleshooting, setup, and supervisory control.
| Parameter |
Specification |
| Display Type |
TFT Color LCD |
| Screen Size |
5.7" |
| Resolution |
640 x 480 (VGA) |
| Display Size (W x H) |
115.2 x 86.4 mm |
| Number of Characters |
16-dot: 40 x 30, 12-dot: 53 x 40 (2-byte) |
| Display Colors |
65,536 colors |
| Intensity Adjustment |
32 levels |
| Backlight Type |
LED (non-replaceable) |
| Backlight Life |
Approx. 60,000 hours (to 50% intensity at 25°C) |
| Touch Panel Type |
Analog resistive film |
| Key Size |
Minimum 2 x 2 dots |
| Simultaneous Press |
Maximum 2 points |
| Touch Life |
1 million+ operations (0.98N or less) |
| Panel Color |
Black |
| Human Sensor Distance |
1 meter |
| Detection Temperature |
Human vs. ambient: ≥4°C difference |
| User Memory |
ROM: 32MB, RAM: 80MB |
| Memory Life |
100,000 writes |
| Internal Clock Accuracy |
±90 sec/month (25°C) |
| Battery Type |
GT11-50BAT lithium |
| Battery Life |
Approx. 5 years (25°C) |
| RS-232 Interface |
1ch: 115200/57600/38400/19200/9600/4800 bps, D-sub 9-pin (male), 32-pin |
| RS-422/485 Interface |
1ch: same speeds, D-sub 9-pin (male), 32-pin |
| Ethernet Interface |
1ch: 10BASE-T/100BASE-TX, RJ-45 |
| USB Host |
1 port, High-Speed 480 Mbps, USB-A |
| USB Device |
1 port, High-Speed 480 Mbps, USB Mini-B |
| SD Card Slot |
1ch, SDHC compliant (max 32GB) |
| Extension Interface |
For communication/option units |
| Auxiliary Extension I/F |
For option units |
| Side Interface |
For LAN communication unit |
| Sound Output |
3.5 mm jack |
| Buzzer Output |
Single tone (adjustable) |
| Power LED |
2 colors (blue, orange) |
| Protection Rating |
Front: IP67F, Panel: IP2X |
| External Dimensions (W x H x D) |
164 x 139 x 53.5 mm |
| Panel Cutout (W x H) |
153 x 121 mm |
| Weight |
0.6 kg (without brackets) |
| Application Software |
GT Works3 V1.180N / 1.195D |
- Connectivity Depth: Dual serial ports (RS-232/422/485) plus Ethernet enable multi-protocol communication with PLCs, drives, and controllers.
- Human Sensor Integration: Detects operator proximity within 1m, ideal for automatic screen wake or safety interlocks.
- Grip Switch Compatibility: Supports optional grip switch (IDE HE3B-M2PB), stop switch (IDE XA1E-BV03R), and keylock switch (IDEC AS6M-2KT1PB) for enhanced handheld control.
- Data Logging: SDHC card slot (up to 32GB) allows extensive data logging, recipe storage, and firmware updates.
- Durability: IP67F front panel and LED backlight rated for 60,000 hours ensure long service life in dusty or wet environments.
- Ergonomics: Lightweight 0.6 kg design with compact footprint reduces operator fatigue during mobile use.
