Mitsubishi GT2506HS-VTBD Handy HMI

Series#: Mitsubishi

Product Details

Mitsubishi GT2506HS-VTBD – 6.5-inch Handy GOT2000 Series HMI with TFT color display.
Compact handheld design with ergonomic grip switch and stop switch for mobile operator control.
High-resolution 640x480 VGA display with 65,536 colors and 32-level intensity adjustment.
Robust connectivity: RS-232, RS-422/485, Ethernet (10BASE-T/100BASE-TX), USB Host/Device, and SDHC slot.
IP65 front protection (handheld) and IP67F front protection (panel-mounted) for harsh environments.
Fast global shipping with full warranty and technical support.
100% Genuine and New, rigorously inspected before international dispatch.

Specification

The Mitsubishi GT2506HS-VTBD is a high-performance handheld HMI from the GOT2000 series, designed for mobile operator control and monitoring in demanding industrial environments. Featuring a 6.5-inch TFT color LCD with 640x480 VGA resolution and 65,536 colors, this unit provides clear, vibrant visuals. Its compact form factor (201x230x97 mm) and lightweight design (1.2 kg) make it ideal for portable applications, while the integrated grip and stop switches enhance ergonomics. With a wide range of built-in interfaces including RS-232, RS-422/485, Ethernet, USB, and SDHC support, the GT2506HS-VTBD ensures seamless integration into existing automation networks. The front panel is rated IP65 for handheld use, offering reliable protection against dust and water ingress.

Parameter	Specification
Display Type	TFT Color LCD
Screen Size	6.5 inches
Resolution	640 x 480 (VGA)
Display Colors	65,536 colors
Backlight	LED (non-replaceable), approx. 60,000 hours life
Touch Panel	Analog resistive film, 2-point simultaneous press
Memory	User ROM: 32 MB, RAM: 80 MB
RS-232 Interface	1 ch, D-sub 9-pin (male), up to 115200 bps
RS-422/485 Interface	1 ch, D-sub 9-pin (female), up to 115200 bps
Ethernet	1 ch, 10BASE-T/100BASE-TX, RJ-45
USB (Host)	1 ch, USB-A, High-Speed 480 Mbps
USB (Device)	1 ch, USB Mini-B, High-Speed 480 Mbps
SD Card Slot	1 ch, SDHC compatible (max 32 GB)
Extension Interface	For communication/option unit mounting
Side Interface	For LAN communication unit mounting
Sound Output	3.5 mm jack
Buzzer	Single tone (adjustable tone and length)
Power LED	2 colors (blue, orange)
Protection Rating	Front: IP65 (handheld), IP67F (panel-mounted); Control panel: IP2X
External Dimensions (W x H x D)	201 x 230 x 97 mm
Weight	1.2 kg (excluding mounting brackets)
Battery	GT11-50BAT lithium, approx. 5 years life at 25°C
Internal Clock Accuracy	±90 sec/month at 25°C
Application Software	GT Designer3 Version 1.170C or later

Grip Switch: IDE HE3B-M2PB (included for handheld operation)
Stop Switch: IDE XA1E-BV03R (integrated emergency stop)
Keylock Switch: IDEC AS6M-2KT1PB (optional for added security)
Memory Life: 100,000 write cycles for user memory
Temperature Differential: Human sensor detects temperature difference ≥4°C from ambient
Panel Cutout (if mounted): Not applicable for handheld unit; panel-mount dimensions vary
