The Mitsubishi GT2712-STBD is a flagship 12.1-inch SVGA HMI from the GOT2000 series, engineered for demanding industrial automation environments. This model delivers a perfect balance of screen real estate and compact footprint, featuring a 316 x 246 x 52 mm panel with a 302 x 228 mm cutout. With its high-brightness TFT LCD, 65,536-color display, and 32-level intensity adjustment, operators benefit from exceptional readability even in challenging lighting. The unit is built for longevity, with an LED backlight rated at 60,000 hours and a touch panel life exceeding 1 million actuations. The GT2712-STBD is equipped with a comprehensive interface suite, including a 10BASE-T/100BASE-TX Ethernet port, dual RS-232/422/485 serial channels, two USB host ports (480Mbps), and a USB Mini-B device port, alongside an SDHC-compatible card slot. Its protective construction meets IP67F on the front (when mounted in a panel) and IP2X internally, ensuring resilience against dust and water ingress. Powered by a robust memory architecture—57MB for storage and 128MB for operation—and backed by an internal clock with ±90 sec/month accuracy, this HMI is ideal for complex SCADA, machine control, and data logging applications.
| Parameter |
Specification |
| Display Type |
TFT Color LCD |
| Screen Size |
12.1" |
| Resolution (Dots) |
800 x 600 (SVGA) |
| Display Size (W x H) mm |
246.0 x 184.5 |
| Display Colors |
65,536 Colors |
| Intensity Adjustment |
32-Level Adjustment |
| Backlight Type |
LED (Not Replaceable) |
| Backlight Life |
Approx. 60,000 hours or more (to 50% intensity at 25°C) |
| Touch Panel Type |
Analog Resistive Film |
| Touch Panel Life |
1 Million times or more (0.98N or less) |
| Panel Color |
Black |
| Human Sensor Detection Distance |
1m |
| Detection Temperature |
Temperature difference ≥ 4°C |
| User Memory (ROM) |
57MB |
| Operation Memory (RAM) |
128MB |
| Memory Write Life |
100,000 times |
| Internal Clock Accuracy |
±90 sec/month (at 25°C) |
| Battery Type |
GT11-50BAT Lithium Battery |
| Battery Life |
Approx. 5 years (at 25°C) |
| RS-232 Interface |
1ch, D-sub 9-pin (male), up to 115200bps |
| RS-422/485 Interface |
1ch, D-sub 9-pin (female), up to 115200bps |
| Ethernet Interface |
1ch, 10BASE-T/100BASE-TX, RJ-45 |
| USB (Host) |
2ch (front/rear), High-Speed 480Mbps, USB-A |
| USB (Device) |
1ch (front), High-Speed 480Mbps, USB Mini-B |
| SD Card Slot |
1ch, SDHC compliant (max 32GB) |
| Extension Interface |
For communication/option unit mounting |
| Auxiliary Extension I/F |
For option unit mounting |
| Side Interface |
For communication unit mounting |
| Buzzer Output |
Single tone (tone, length adjustable) |
| Power LED |
2 colors: blue, orange |
| Protective Construction |
Front: IP67F (*5,*8); In panel: IP2X |
| External Dimensions (W x H x D) mm |
316 x 246 x 52 |
| Panel Cutout (W x H) mm |
302 x 228 |
| Weight (excl. brackets) kg |
2.4 |
| Application Software Package |
1.100E or later |
- Multi-Protocol Support: Seamless connectivity with Mitsubishi PLCs and third-party devices via built-in serial and Ethernet ports.
- High-Speed Data Transfer: USB 2.0 High-Speed (480Mbps) for rapid project downloads and data logging.
- Expandable Architecture: Dedicated extension and side interfaces allow for optional communication units and function modules.
- Human Sensor Integration: Built-in sensor detects operator presence up to 1m, enabling energy-saving screen dimming or wake-on-approach.
- Ruggedized Design: IP67F front panel ensures resistance to dust and water jets, ideal for washdown or harsh industrial floors.
- Long-Term Reliability: LED backlight with 60,000-hour lifespan and battery-backed real-time clock for years of maintenance-free operation.
- Large Storage Capacity: 57MB flash ROM for storing extensive HMI projects, recipes, and alarm logs without external media.
