The GT2710-VTBD is a 10.4-inch Mitsubishi GOT2000 Series HMI designed for advanced machine control and monitoring. It combines a high-contrast VGA TFT LCD with a durable analog resistive touch screen, ensuring reliable performance in harsh industrial environments. With its rich interface set and robust memory, this unit is ideal for applications requiring fast data exchange and long-term stability.
| Parameter |
Specification |
| Display Type |
TFT Color LCD |
| Screen Size |
10.4″ |
| Resolution |
640 x 480 (VGA) |
| Display Size (W x H) |
211.1 x 158.4 mm |
| Display Colors |
65,536 colors |
| Intensity Adjustment |
32-level adjustment |
| Backlight Type |
LED (non-replaceable) |
| Backlight Life |
Approx. 60,000 hours (to 50% brightness at 25°C) |
| Touch Panel Type |
Analog Resistive Film |
| Touch Panel Life |
1 million+ operations (0.98N or less) |
| Panel Color |
Black |
| Human Sensor Detection Distance |
1 m |
| Detection Temperature |
ΔT ≥ 4°C (body vs ambient) |
| User Memory (ROM) |
57 MB |
| User Memory (RAM) |
128 MB |
| Memory Write Life |
100,000 times |
| Internal Clock Accuracy |
±90 sec/month (25°C) |
| Battery Type |
GT11-50BAT (Lithium) |
| Battery Life |
Approx. 5 years (25°C) |
| RS-232 Interface |
1 ch, D-sub 9-pin (male), up to 115200 bps |
| RS-422/485 Interface |
1 ch, D-sub 9-pin (female), up to 115200 bps |
| Ethernet Interface |
1 ch, 10BASE-T/100BASE-TX, RJ-45 |
| USB (Host) |
2 ch (front/rear), USB-A, High-Speed 480 Mbps |
| USB (Driver) |
1 ch (front), USB Mini-B, High-Speed 480 Mbps |
| SD Card Slot |
1 ch, SDHC compliant (max 32 GB) |
| Extension Interface |
For communication/option units |
| Auxiliary Extension I/F |
For option units |
| Side Interface |
For communication units |
| Buzzer Output |
Single tone (adjustable tone/length) |
| Power LED |
2 colors (blue, orange) |
| Protective Construction |
Front: IP67F; In panel: IP2X |
| External Dimensions (W x H x D) |
303 x 218 x 52 mm |
| Panel Cutout (W x H) |
289 x 200 mm |
| Weight (without brackets) |
2.1 kg |
| Application Software |
GT Designer3 Package 1 Ver.1.100E or later |
- Memory & Storage: 57 MB ROM for project storage, 128 MB RAM for runtime operations, ensuring smooth multitasking and large project handling.
- Connectivity: Dual USB host ports (front and rear) for peripherals like keyboards or barcode scanners, plus a dedicated USB driver port for programming.
- Environmental Resistance: IP67F front panel protection against dust and water jets, suitable for washdown or dusty environments.
- Human Sensor: Built-in pyroelectric sensor detects operator presence within 1 meter, enabling smart power-saving or security functions.
- Expansion Options: Side and auxiliary interfaces support additional communication modules, such as CC-Link or PROFIBUS, for system scalability.
