Mitsubishi GT2708-STBA Touch Screen HMI 8.4"

Series#: Mitsubishi

Product Details

Model: 8.4″ Mitsubishi Touch screen HMIs GT2708-STBA – High-performance GOT2000 Series HMI.
Display: 8.4-inch TFT color LCD with 800x600 SVGA resolution for crisp, clear visuals.
Robust Construction: IP67F front protection (in panel IP2X) for demanding industrial environments.
High-Speed Connectivity: Equipped with Ethernet, RS-232, RS-422/485, and dual USB (Host/Driver) ports.
Generous Memory: 57MB storage ROM and 128MB RAM for complex applications and fast data handling.
Long-Life LED Backlight: 60,000+ hour LED backlight (non-replaceable) ensures years of reliable operation.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The 8.4″ Mitsubishi Touch screen HMIs GT2708-STBA is a compact yet powerful operator interface from the renowned GOT2000 series, designed to streamline machine control and monitoring. This model delivers an optimal balance of screen size and performance, featuring an 8.4-inch SVGA TFT LCD with 65536 colors for exceptional readability. With its robust IP67F-rated front panel, high-speed communication interfaces, and ample memory, the GT2708-STBA is the ideal solution for mid-range automation tasks requiring reliability and precision.

Parameter	Specification
Display Type	TFT Color LCD
Screen Size	8.4 inches
Resolution	800 x 600 (SVGA)
Display Size (W x H)	170.9 x 128.2 mm
Display Colors	65536 Colors
Backlight Type	LED (non-replaceable)
Backlight Life	Approx. 60,000 hours or more (at 25°C)
Touch Panel	Analog Resistive Film
Touch Panel Life	1 million times or more (0.98N or less)
Panel Color	Black
Protective Construction	Front: IP67F (5,8), In Panel: IP2X
External Dimensions (WxHxD)	241 x 194 x 52 mm
Panel Cutout (WxH)	227 x 176 mm
Weight (excl. brackets)	Approx. 1.5 kg
User Memory (ROM)	57 MB
User Memory (RAM)	128 MB
Internal Clock Accuracy	±90 sec/month (at 25°C)
Battery	GT11-50BAT lithium battery (approx. 5-year life)
Application Software	GT Works3 Version 1.130L or later

Communication Interfaces: Ethernet (10BASE-T/100BASE-TX) via RJ-45; RS-232 (D-sub 9-pin male); RS-422/485 (D-sub 9-pin female); USB Host (2 channels, High-Speed 480Mbps, USB-A); USB Driver (1 channel, High-Speed 480Mbps, USB Mini-B).
Expansion Capabilities: Extension Interface for communication/option units; Auxiliary Extension I/F and Side Interface for additional option modules.
Human Sensor & Buzzer: Human sensor with 1m detection distance and 4°C temperature differential sensitivity; Buzzer output (single tone, adjustable).
Power & Indication: Power LED with dual-color emission (blue/orange).
Data Storage: SD card slot (1 channel, SDHC compliant, up to 32GB).
Character Display: 16-dot standard font: 50 characters x 37 lines (2-byte); 12-dot standard font: 66 characters x 50 lines (2-byte).
