The GOT 2000 Series GT27 GT2710-STBD is a 10.4-inch Mitsubishi touch screen HMI engineered for advanced automation environments. This model delivers a crisp SVGA resolution (800 x 600 dots) on a TFT color LCD display with 65,536 colors, ensuring detailed visualization of complex processes. The unit features a robust analog resistive film touch panel rated for over 1 million presses, supports dual-point simultaneous input, and includes a human sensor with 1-meter detection range for energy-saving operation. With a comprehensive interface suite—including RS-232, RS-422/485, Ethernet (10BASE-T/100BASE-TX), dual USB host ports (480 Mbps), and an SDHC card slot (up to 32 GB)—the GT2710-STBD integrates seamlessly into existing control networks. The front panel meets IP67F standards for dust and water ingress, while the internal clock maintains ±90 seconds/month accuracy at 25°C, backed by a GT11-50BAT lithium battery with a 5-year service life. Designed for reliability, this HMI operates with 57 MB of user storage ROM and 128 MB of operation RAM, and is compatible with GT Designer3 software (version 1.100E or later).
| Parameter |
Specification |
| Display Type |
TFT Color LCD |
| Screen Size |
10.4″ |
| Resolution |
800 x 600 (SVGA) |
| Display Area (WxH) |
211.1 x 158.4 mm |
| Display Colors |
65,536 colors |
| Intensity Adjustment |
32 levels |
| Backlight Type |
LED (non-replaceable) |
| Backlight Life |
≥60,000 hours (to 50% brightness at 25°C) |
| Touch Panel Type |
Analog resistive film |
| Touch Panel Life |
≥1 million operations (0.98N or less) |
| Simultaneous Press Points |
Maximum 2 |
| Panel Color |
Black |
| Human Sensor Detection |
1 meter, ΔT ≥ 4°C |
| User Memory (ROM) |
57 MB |
| Operation Memory (RAM) |
128 MB |
| Memory Write Life |
100,000 times |
| Internal Clock Accuracy |
±90 sec/month at 25°C |
| Battery Type |
GT11-50BAT lithium |
| Battery Life |
Approx. 5 years at 25°C |
| RS-232 Interface |
1 ch, D-sub 9-pin (male), up to 115200 bps |
| RS-422/485 Interface |
1 ch, D-sub 9-pin (female), up to 115200 bps |
| Ethernet |
1 ch, 10BASE-T/100BASE-TX, RJ-45 |
| USB Host |
2 ch (front/rear), USB-A, 480 Mbps |
| USB Device |
1 ch (front), USB Mini-B, 480 Mbps |
| SD Card Slot |
1 ch, SDHC compliant (max 32 GB) |
| Extension Interface |
For communication/option units |
| Auxiliary Extension I/F |
For option unit mounting |
| Side Interface |
For communication unit mounting |
| Buzzer Output |
Single tone, adjustable |
| Power LED |
2 colors (blue/orange) |
| Protective Construction |
Front: IP67F; Rear (panel): IP2X |
| External Dimensions (WxHxD) |
303 x 218 x 52 mm |
| Panel Cutout (WxH) |
289 x 200 mm |
| Weight (excluding brackets) |
2.1 kg |
| Software Compatibility |
GT Designer3 v1.100E or later |
- Display Performance: 10.4″ SVGA TFT with 65,536 colors and 32-level backlight dimming ensures clear, readable graphics even in variable lighting.
- Touch Reliability: Analog resistive film rated for >1 million actuations and 2-point multi-touch support for intuitive operator interaction.
- Human Sensor Integration: Built-in passive infrared sensor (1m range, ΔT ≥ 4°C) enables automatic screen dimming to extend backlight life and reduce power consumption.
- Memory Architecture: 57 MB non-volatile ROM for project storage and 128 MB RAM for runtime operations, providing ample headroom for complex HMI applications.
- Industrial Connectivity: Dual serial ports (RS-232/422/485), Ethernet for network integration, and dual USB host ports for data logging or peripheral connection.
- Environmental Durability: IP67F front panel protection against dust and water jets, with IP2X rear enclosure for safe panel-mount installation.
- Expandability: Dedicated extension and side interfaces allow for optional communication units or additional I/O modules.
