The MITSUBISHI MELSERVO-J4 SERVOMOTOR WITH BREAK 3.5KW HG-SR352BJ is a cornerstone of the HG-SR 2000 r/min series, specifically engineered for 3-phase 200 V AC systems requiring medium inertia and medium capacity. This servo motor combines advanced electromagnetic design with a robust mechanical construction to deliver exceptional torque density and dynamic response. The HG-SR352BJ is ideal for high-speed pick-and-place, packaging, and material handling applications where precision and reliability are paramount. Its integrated brake ensures safe operation in vertical or gravity-loaded axes, while the motor’s IP rating and sealed bearings provide durability in harsh industrial environments. Backed by Mitsubishi’s MELSERVO-J4 platform, this model supports high-resolution encoders for closed-loop feedback, enabling sub-micron positioning accuracy in servo drive systems.
| Parameter |
Unit |
HG-SR352BJ (2000 r/min Series) |
| Rated Output |
kW |
3.5 |
| Rated Torque |
N·m |
16.7 |
| Maximum Torque |
N·m |
50.1 |
| Rated Speed |
r/min |
2000 |
| Maximum Speed |
r/min |
3000 |
| Instantaneous Permissible Speed |
r/min |
3450 |
| Power Rate at Continuous Rated Torque |
kW/s |
35.5 |
| Rated Current |
A |
14 |
| Maximum Current |
A |
45 |
| Ambient Temperature (Operation) |
°C |
0 to 40 (non-freezing) |
| Ambient Temperature (Storage) |
°C |
-15 to 70 (non-freezing) |
| Ambient Humidity (Operation) |
%RH |
10 to 80 (non-condensing) |
| Ambient Humidity (Storage) |
%RH |
10 to 90 (non-condensing) |
| Permissible Load for Shaft (L) |
mm |
79 |
| Radial Load |
N |
2058 |
| Thrust Load |
N |
980 |
| Mass (Standard) |
kg |
16 |
