Omron CP2E Series Micro PLC Module CP2E-N40DT-A

Series#: Omron

Product Details

Omron Micro PLC Module CP2E Series CP2E-N40DT-A and CP2E-N40DT-D: High-performance controllers with 40 I/O points.
Dual power supply options: AC (100-240 VAC) or DC (24 VDC) to suit diverse industrial environments.
Compact panel-mount design: 90mm x 80mm x 150mm, ideal for space-constrained automation cabinets.
Wide operating temperature range: -20 to 60°C, ensuring reliable performance in harsh conditions.
Built-in noise immunity: 2 kV power line resistance per IEC61000-4-4 for stable operation.
Integrated 24 VDC external power supply (300 mA) on AC models for sensor/actuator support.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Omron CP2E-N40DT-A and CP2E-N40DT-D are part of the renowned CP2E Series micro PLC modules, engineered for advanced machine control and automation tasks. These 40-I/O-point units deliver exceptional flexibility with AC or DC power inputs, supporting both line and DC bus configurations. Designed for panel mounting, they offer a robust solution for OEMs and system integrators requiring reliable, scalable control in compact form factors. With 100% original Omron components, these modules ensure long-term durability and seamless integration into existing systems.

Parameter	CP2E-N40DT-A (AC Power)	CP2E-N40DT-D (DC Power)
Supply Voltage	100 to 240 VAC, 50/60 Hz	24 VDC
Operating Voltage Range	85 to 264 VAC	20.4 to 26.4 VDC
Power Consumption	50 VA max. (100 VAC) / 70 VA max. (240 VAC)	20 W max.
Inrush Current	120 VAC: 20 A for 8 ms max.; 240 VAC: 40 A for 8 ms max.	24 VDC: 30 A for 20 ms max.
External Power Supply	24 VDC, 300 mA	Not provided
Insulation Resistance	20 MΩ min. at 500 VDC between AC and GR terminals	Not isolated
Dielectric Strength	2,300 VAC for 1 min between AC and GR terminals	Not isolated
Power Interrupt Time	10 ms min.	2 ms min.
Dimensions (H x D x W)	90 mm x 80 mm x 150 mm
Weight	640 g max.
Ambient Operating Temperature	-20 to 60°C
Ambient Humidity	10% to 90%
Atmosphere	No corrosive gas
Ambient Storage Temperature	-20 to 75°C (excluding battery)
Altitude	2,000 m max.
Pollution Degree	2 or less (conforms to IEC61010-2-201)
Noise Resistance	2 kV on power supply line (conforms to IEC61000-4-4)
Overvoltage Category	Category II (conforms to IEC61010-2-201)
EMC Immunity Level	Zone B
Vibration Resistance	5 to 8.4 Hz: 3.5 mm amplitude; 8.4 to 150 Hz: 9.8 m/s² acceleration for 100 min in X, Y, Z
Shock Resistance	147 m/s², 3 times in X, Y, Z directions (conforms to IEC60068-2-27)

I/O Configuration: 40 I/O points (24 inputs, 16 outputs) with transistor (sink/source) outputs for high-speed switching.
Communication: Built-in RS-232C and USB ports for programming and HMI connectivity; optional Ethernet expansion via CP1W-CIF41.
Programming Capabilities: Supports ladder logic with up to 8K steps, 16-bit timers/counters, and advanced math functions.
Protection Features: Overcurrent protection on outputs, reverse polarity protection on DC models, and built-in watchdog timer.
Environmental Compliance: RoHS compliant and meets CE, UL, and cUL standards for global installations.
Expansion Options: Compatible with CP1W series I/O expansion units for up to 120 I/O points total.
Diagnostics: LED indicators for power, run, error, and individual I/O status for quick troubleshooting.
