Omron CP2E Series Micro PLC Module CP2E-N60DR-A

Series#: Omron

Product Details

Model: Omron CP2E-N60DR-A – High-performance Micro PLC Module with 60 I/O points for compact automation.
AC Power Supply (100–240 VAC) – Robust industrial-grade input with wide voltage tolerance.
Expandable I/O – Ideal for small to medium-scale control systems with relay outputs.
Rugged Design – Panel-mountable, operates from -20°C to 60°C with high noise immunity.
Fast Delivery – In-stock units shipped within 24 hours, no minimum order required.
100% Genuine and New, rigorously inspected before international dispatch.

Specification

The Omron CP2E-N60DR-A is a versatile Micro PLC Module from the CP2E Series, engineered for reliable and cost-effective automation in demanding industrial environments. This AC-powered unit features 60 I/O points (including relay outputs), making it an excellent choice for controlling conveyors, packaging machines, and material handling systems. With a compact footprint of 90mm × 80mm × 195mm and weighing only 780g max, it integrates seamlessly into control panels while delivering robust performance across a wide temperature range.

Item	AC Power Supply (CP2E-N60DR-A)	DC Power Supply (CP2E-N60DR-D)
Model	CP2E-N60DR-A	CP2E-N60DR-D
Enclosure	Mounted in a panel
Dimensions (H × D × W)	90mm × 80mm × 195mm
Weight	780g max.
Supply voltage	100 to 240 VAC 50/60 Hz	24 VDC
Operating voltage range	85 to 264 VAC	20.4 to 26.4 VDC
Power consumption	50 VA/100 VAC max. (CP2E-@30/40/60D@-A), 70 VA/240 VAC max.	20W max. (CP2E-@30/40/60D@-D)
Inrush current	120 VAC, 20 A for 8 ms max. at cold start; 240 VAC, 40 A for 8 ms max.	24 VDC, 30 A for 20 ms max. at cold start
External power supply	24 VDC, 300 mA (provided for 30/40/60 I/O models)	Not provided
Insulation resistance	20 MΩ min. at 500 VDC between AC external and GR terminals	Not isolated between primary and secondary DC supplies
Dielectric strength	2,300 VAC 50/60 Hz for 1 min between AC external and GR terminals; leakage current 5 mA max.	Not isolated between primary and secondary DC supplies
Power interrupt time	10 ms min.	2 ms min.
Ambient operating temperature	-20 to 60°C
Ambient humidity	10% to 90%
Atmosphere	No corrosive gas
Ambient storage temperature	-20 to 75°C (excluding battery)
Altitude	2,000 m max.
Pollution degree	2 or less (conforms to IEC61010-2-201)
Noise resistance	2 kV on power supply line (conforms to IEC61000-4-4)
Overvoltage category	Category II (conforms to IEC61010-2-201)
EMC immunity level	Zone B
Vibration resistance	Conforms to IEC60068-2-6: 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz at 9.8 m/s² for 100 min in X, Y, Z
Shock resistance	Conforms to IEC60068-2-27: 147 m/s², 3 times in X, Y, Z directions

I/O Configuration: 60 I/O points with relay outputs for high-current switching (e.g., motors, solenoids).
Communication: Built-in USB port for programming and monitoring via CX-One software.
Programming: Supports ladder diagram, structured text, and function blocks for flexible control logic.
Expansion Capability: Up to 3 expansion units for additional I/O or analog modules.
Protection Features: Overcurrent and short-circuit protection on outputs; watchdog timer for system reliability.
Mounting: Direct panel mounting with DIN rail compatible adapters (optional).
Certifications: CE, UL, and cUL listed for global industrial compliance.
