The Omron CP2E-N60DT-D and CP2E-N60DT1-D are advanced micro PLC modules from the CP2E series, engineered for demanding industrial automation tasks. These 60-I/O-point units offer a robust DC-powered solution with exceptional flexibility, supporting up to 40 I/O expansion modules. Designed for panel mounting, they deliver reliable performance in temperature extremes from -20°C to 60°C and feature high noise resistance (2 kV on power supply line). With 100% original factory-new components and rapid global shipping, these PLCs ensure seamless integration into new or existing systems.
| Parameter |
CP2E-N60DT-D / CP2E-N60DT1-D |
| Power Supply |
24 VDC |
| Operating Voltage Range |
20.4 to 26.4 VDC |
| Power Consumption |
20W max. (CP2E-@30/40/60D@-D) |
| Inrush Current |
24 VDC, 30A for 20 ms max. (cold start at room temperature) |
| External Power Supply |
Not provided |
| Insulation Resistance |
Not isolated between primary and secondary DC power supplies |
| Dielectric Strength |
Not isolated between primary and secondary DC power supplies |
| Power Interrupt Time |
2 ms min. |
| Ambient Operating Temperature |
-20 to 60°C |
| Ambient Humidity |
10% to 90% |
| Atmosphere |
No corrosive gas |
| Ambient Storage Temperature |
-20 to 75°C (excluding battery) |
| Altitude |
2,000 m max. |
| Pollution Degree |
2 or less (conforms to IEC61010-2-201) |
| Noise Resistance |
2 kV on power supply line (conforms to IEC61000-4-4) |
| Overvoltage Category |
Category II (conforms to IEC61010-2-201) |
| EMC Immunity Level |
Zone B |
| Vibration Resistance |
Conforms to IEC60068-2-6: 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz at 9.8 m/s² for 100 min in X, Y, Z directions (10 sweeps of 10 min each) |
| Shock Resistance |
Conforms to IEC60068-2-27: 147 m/s², 3 times in X, Y, Z directions |
- Dimensions (H × D × W): CPU Unit with 60 I/O points: 90 mm × 80 mm × 195 mm
- Weight: CPU Unit with 60 I/O points: 780g max.
- Enclosure: Panel-mount design for easy installation in control cabinets
- I/O Configuration: 60 I/O points with transistor outputs (sink/source) for high-speed switching
- Communication: Built-in Ethernet port (10/100 Mbps) for network connectivity and programming via CX-One software
- Programming: Supports ladder logic, structured text, and function block diagrams for flexible control
- Expansion: Up to 40 expansion units for additional I/O, analog, and communication modules
- Certification: CE, UL, and cUL listed for global compliance
