The Omron CP2E-S40DT1-D and CP2E-S60DT1-D are part of the CP2E Series, offering a scalable platform for precise machine control. These Micro PLC Modules combine a DC-powered CPU with a generous I/O count, making them suitable for applications requiring reliable digital I/O handling in harsh environments. With a panel-mount enclosure and comprehensive electrical protection, the CP2E-S40DT1-D and CP2E-S60DT1-D deliver consistent performance in temperature extremes and high-electrical-noise settings. Below is the detailed technical specification.
| Specification |
AC Power Supply |
DC Power Supply |
| Item |
AC power supply |
DC power supply |
| Model |
CP2E-Standard D@-A |
CP2E-Standard D@-D |
| Enclosure |
Mounted in a panel |
| Dimensions (H × D × W) |
CPU Unit with 14 or 20 I/O points (CP2E-@14/20D@-@): 90mm × 80mm × 86mm
CPU Unit with 30 I/O points (CP2E-@30D@-@): 90mm × 80mm × 130mm
CPU Unit with 40 I/O points (CP2E-@40D@-@): 90mm × 80mm × 150mm
CPU Unit with 60 I/O points (CP2E-@60D@-@): 90mm × 80mm × 195mm |
| Weight |
CPU Unit with 14 I/O points (CP2E-@14D@-@): 335g max.
CPU Unit with 20 I/O points (CP2E-@20D@-@): 340g max.
CPU Unit with 30 I/O points (CP2E-@30D@-@): 580g max.
CPU Unit with 40 I/O points (CP2E-@40D@-@): 640g max.
CPU Unit with 60 I/O points (CP2E-@60D@-@): 780g max. |
| Supply voltage |
100 to 240 VAC 50/60 Hz |
24 VDC |
| Operating voltage range |
85 to 264 VAC |
20.4 to 26.4 VDC |
| Power consumption |
15 VA/100 VAC max. (CP2E-@14/20D@-A)
25 VA/240 VAC max.
50 VA/100 VAC max. (CP2E-@30/40/60D@-A)
70 VA/240 VAC max. |
13W max. (CP2E-@14/20D@-D)
20W max. (CP2E-@30/40/60D@-D) |
| Inrush current |
120 VAC, 20 A for 8 ms max. for cold start at room temperature
240 VAC, 40 A for 8 ms max. for cold start at room temperature |
24 VDC, 30A for 20 ms max. for cold start at room temperature |
| External power supply |
Not provided. (CP2E-@14/20D@-A)
24 VDC, 300 mA (CP2E-@30/40/60D@-A) |
Not provided. |
| Insulation resistance |
20 MΩ min. (at 500 VDC) between the external AC terminals and GR terminals |
Not isolated between primary and secondary DC power supplies |
| Dielectric strength |
2,300 VAC 50/60Hz for 1 min between AC external and GR terminals
Leakage current: 5 mA max. |
Not isolated between primary and secondary DC power supplies |
| Power interrupt time |
10 ms min. |
2 ms min. |
| Ambient operating temperature |
-20 to 60°C |
| Ambient humidity |
10% to 90% |
| Atmosphere |
No corrosive gas. |
| Ambient storage temperature |
-20 to 75°C (excluding battery) |
| Altitude |
2,000 m max. |
| Pollution degree |
2 or less: Conforms to IEC61010-2-201. |
| Noise resistance |
2 kV on power supply line (Conforms to IEC61000-4-4.) |
| Overvoltage category |
Category II: Conforms to IEC61010-2-201. |
| EMC immunity level |
Zone B |
| Vibration resistance |
Conforms to IEC60068-2-6. 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz
Acceleration of 9.8 m/s² for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total) |
| Shock resistance |
Conforms to IEC60068-2-27. 147 m/s², 3 times in X, Y, and Z directions |
- Power Supply Flexibility: The CP2E-S40DT1-D and CP2E-S60DT1-D operate on 24 VDC with a wide tolerance (20.4 to 26.4 VDC), ensuring stable performance even with fluctuating DC sources.
- Environmental Resilience: Rated for -20 to 60°C ambient temperature and 10% to 90% humidity, with no corrosive gas atmosphere, making it suitable for factory floors and harsh industrial settings.
- Electrical Protection: Dielectric strength of 2,300 VAC (AC models) and noise immunity per IEC61000-4-4 (2 kV) guarantee robust operation in electrically noisy environments.
- Mechanical Robustness: Vibration resistance per IEC60068-2-6 (5 to 150 Hz, 9.8 m/s²) and shock resistance per IEC60068-2-27 (147 m/s²) ensure durability under mechanical stress.
- Compact & Lightweight: With dimensions as low as 90mm × 80mm × 150mm for 40 I/O and weight under 800g, these modules save panel space without sacrificing I/O capacity.
- Compliance & Standards: Conforms to IEC61010-2-201 for pollution degree 2 and overvoltage category II, with EMC immunity level Zone B for reliable operation in industrial environments.
