Omron CP2E Series Micro PLC Module CP2E-N30DR-D

Series#: Omron

Product Details

Omron CP2E-N30DR-D and CP2E-N60DR-D – High-performance Micro PLC Modules from the trusted CP2E Series.
Compact all-in-one design with 30 or 60 I/O points, ideal for small to medium automation tasks.
Robust 24 VDC power supply with wide operating range (20.4 to 26.4 VDC) for stable operation.
Built-in high-speed processing and versatile communication ports for seamless integration.
Rugged construction with panel mounting, wide temperature tolerance (-20 to 60°C), and industrial-grade noise immunity.
Fast delivery – stock available, shipped within 24 hours to keep your production on track.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Omron CP2E Series Micro PLC Modules, specifically the CP2E-N30DR-D and CP2E-N60DR-D models, represent a reliable and cost-effective solution for distributed control in industrial automation. These 24 VDC-powered units deliver precise logic control with 30 and 60 I/O points respectively, making them perfect for packaging, material handling, or small machine automation. With a compact footprint, wide environmental tolerance, and proven Omron engineering, the CP2E-N30DR-D and CP2E-N60DR-D ensure long-term performance in demanding factory floor conditions. Each module is 100% original and new, backed by full technical support.

Item	Specification (CP2E-N30DR-D / CP2E-N60DR-D)
Model	CP2E-N30DR-D (30 I/O) / CP2E-N60DR-D (60 I/O)
Power Supply	24 VDC (20.4 to 26.4 VDC)
Power Consumption	20W max (for 30/40/60 I/O models)
Inrush Current	24 VDC, 30A for 20 ms max (cold start at room temp)
External Power Supply	Not provided
Enclosure	Panel-mounted
Dimensions (H x D x W)	CP2E-N30DR-D: 90mm x 80mm x 130mm; CP2E-N60DR-D: 90mm x 80mm x 195mm
Weight	CP2E-N30DR-D: 580g max; CP2E-N60DR-D: 780g max
Ambient Operating Temperature	-20 to 60°C
Ambient Humidity	10% to 90%
Atmosphere	No corrosive gas
Ambient Storage Temperature	-20 to 75°C (excluding battery)
Altitude	2,000 m max
Pollution Degree	2 or less (Conforms to IEC61010-2-201)
Noise Resistance	2 kV on power supply line (Conforms to IEC61000-4-4)
Overvoltage Category	Category II (Conforms to IEC61010-2-201)
EMC Immunity Level	Zone B
Vibration Resistance	Conforms to IEC60068-2-6: 5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz acceleration of 9.8 m/s² for 100 min in X, Y, Z
Shock Resistance	Conforms to IEC60068-2-27: 147 m/s², 3 times in X, Y, Z

Key Technical Highlights:

Core I/O Configuration: The CP2E-N30DR-D provides 30 I/O points, while the CP2E-N60DR-D offers 60 I/O points, both with relay output for flexible field wiring.
Power Integrity: Operates on 24 VDC with a wide tolerance of 20.4 to 26.4 VDC, featuring a robust inrush current handling of 30A for 20 ms to ensure startup reliability.
Environmental Resilience: Rated for -20 to 60°C operating temperature and 10% to 90% humidity, with a storage range of -20 to 75°C, suitable for harsh industrial environments.
EMC and Safety Compliance: Meets IEC61010-2-201 for pollution degree 2 and overvoltage category II, with 2 kV noise resistance on the power line (IEC61000-4-4) for stable operation in electrically noisy settings.
Mechanical Robustness: Vibration resistance per IEC60068-2-6 (5-150 Hz, 9.8 m/s²) and shock resistance per IEC60068-2-27 (147 m/s², 3 times per axis) ensures long-term durability.
