The Omron CP2E Series Micro PLC Modules, specifically the CP2E-S40DT-D, CP2E-S30DR-A, and CP2E-S60DT-D, are engineered for demanding industrial control applications. These compact controllers offer a robust blend of processing power and I/O flexibility, supporting both AC and DC power configurations. With a wide ambient operating temperature range and high resistance to electrical noise, the CP2E series ensures stable performance in harsh environments, making it ideal for machine automation, packaging, and material handling systems.
| Specification |
AC Power Supply |
DC Power Supply |
| Model |
CP2E-Standard D@-A |
CP2E-Standard D@-D |
| Enclosure |
Mounted in a panel |
| Dimensions (H × D × W) |
CPU Unit with 14 or 20 I/O points (CP2E-@14/20D@-@): 90mm *1 × 80mm *2 × 86mm
CPU Unit with 30 I/O points (CP2E-@30D@-@): 90mm *1 × 80mm *2 × 130mm
CPU Unit with 40 I/O points (CP2E-@40D@-@): 90mm *1 × 80mm *2 × 150mm
CPU Unit with 60 I/O points (CP2E-@60D@-@): 90mm *1 × 80mm *2 × 195mm |
| Weight |
CPU Unit with 14 I/O points (CP2E-@14D@-@): 335g max.
CPU Unit with 20 I/O points (CP2E-@20D@-@): 340g max.
CPU Unit with 30 I/O points (CP2E-@30D@-@): 580g max.
CPU Unit with 40 I/O points (CP2E-@40D@-@): 640g max.
CPU Unit with 60 I/O points (CP2E-@60D@-@): 780g max. |
| Supply voltage |
100 to 240 VAC 50/60 Hz |
24 VDC |
| Operating voltage range |
85 to 264 VAC |
20.4 to 26.4 VDC |
| Power consumption |
15 VA/100 VAC max. (CP2E-@14/20D@-A)
25 VA/240 VAC max.
50 VA/100 VAC max. (CP2E-@30/40/60D@-A)
70 VA/240 VAC max. |
13W max. (CP2E-@14/20D@-D)
20W max. (CP2E-@30/40/60D@-D) *4 |
| Inrush current |
120 VAC, 20 A for 8 ms max. for cold start at room temperature
240 VAC, 40 A for 8 ms max. for cold start at room temperature |
24 VDC, 30A for 20 ms max. for cold start at room temperature |
| External power supply *3 |
Not provided. (CP2E-@14/20D@-A)
24 VDC, 300 mA (CP2E-@30/40/60D@-A) |
Not provided. |
| Insulation resistance |
20 MΩ min. (at 500 VDC) between the external AC terminals and GR terminals |
Not isolated between primary and secondary DC power supplies |
| Dielectric strength |
2,300 VAC 50/60Hz for 1 min between AC external and GR terminals
Leakage current: 5 mA max. |
Not isolated between primary and secondary DC power supplies |
| Power interrupt time |
10 ms min. |
2 ms min. |
| Ambient operating temperature |
-20 to 60°C |
| Ambient humidity |
10% to 90% |
| Atmosphere |
No corrosive gas. |
| Ambient storage temperature |
-20 to 75°C (excluding battery) |
| Altitude |
2,000 m max. |
| Pollution degree |
2 or less: Conforms to IEC61010-2-201. |
| Noise resistance |
2 kV on power supply line (Conforms to IEC61000-4-4.) |
| Overvoltage category |
Category II: Conforms to IEC61010-2-201. |
| EMC immunity level |
Zone B |
| Vibration resistance |
Conforms to IEC60068-2-6.5 to 8.4 Hz with 3.5-mm amplitude, 8.4 to 150 Hz
Acceleration of 9.8 m/s2 for 100 min in X, Y, and Z directions (10 sweeps of 10 min each = 100 min total) |
| Shock resistance |
Conforms to IEC60068-2-27.147 m/s2, 3 times in X, Y, and Z directions |
- Power Supply Flexibility: The CP2E series supports both AC (100-240 VAC) and DC (24 VDC) power inputs, with models like CP2E-S40DT-D using DC and CP2E-S30DR-A using AC, ensuring compatibility with global electrical standards.
- Scalable I/O Configuration: Available in 14, 20, 30, 40, and 60 I/O point versions, allowing precise matching to application requirements from simple to complex automation tasks.
- Rugged Environmental Tolerance: Operates reliably from -20°C to 60°C with 10% to 90% humidity, and withstands vibration up to 9.8 m/s² and shock of 147 m/s² per IEC standards.
- High Electrical Immunity: Features 2 kV noise resistance on the power supply line and conforms to EMC Zone B, minimizing interference in industrial environments.
- Compact Panel-Mount Design: Enclosure dimensions range from 90mm × 80mm × 86mm for 14/20 I/O units to 90mm × 80mm × 195mm for 60 I/O units, optimizing cabinet space.
- Safety and Compliance: Meets overvoltage Category II and Pollution Degree 2 per IEC61010-2-201, with dielectric strength of 2,300 VAC for AC models.
