Omron CP2E Series Micro PLC Module CP2E-N20DR-D

Series#: Omron

Product Details

Omron Micro PLC Module CP2E Series – Models CP2E-N20DR-D, CP2E-N40DR-D, and CP2E-N60DT-A available for versatile automation needs.
Compact, panel-mountable design with scalable I/O from 14 to 60 points for flexible system integration.
Dual power supply options: 100-240 VAC (Model -A) or 24 VDC (Model -D) to suit global installations.
Wide operating temperature range (-20°C to 60°C) and high vibration/shock resistance for harsh industrial environments.
Built-in EMC immunity (Zone B) and noise resistance (2 kV) ensuring stable performance in noisy electrical environments.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Omron Micro PLC Module CP2E Series, including models CP2E-N20DR-D, CP2E-N40DR-D, and CP2E-N60DT-A, delivers robust, cost-effective control for small to medium-scale automation tasks. Designed for panel mounting, these CPU units combine a compact footprint with high reliability, supporting both AC and DC power supplies. Ideal for applications requiring precise timing, counting, and logic control, the CP2E series ensures seamless integration into existing systems with its rich I/O configuration and industrial-grade specifications.

Parameter	AC Power Supply (Model -A)	DC Power Supply (Model -D)
Model	CP2E-Standard D@-A	CP2E-Standard D@-D
Enclosure	Mounted in a panel
Dimensions (H × D × W)	14/20 I/O: 90mm × 80mm × 86mm 30 I/O: 90mm × 80mm × 130mm 40 I/O: 90mm × 80mm × 150mm 60 I/O: 90mm × 80mm × 195mm
Weight	14 I/O: 335g max 20 I/O: 340g max 30 I/O: 580g max 40 I/O: 640g max 60 I/O: 780g max
Supply Voltage	100 to 240 VAC 50/60 Hz	24 VDC
Operating Voltage Range	85 to 264 VAC	20.4 to 26.4 VDC
Power Consumption	15 VA (14/20 I/O) / 50 VA (30/40/60 I/O) at 100 VAC 25 VA / 70 VA at 240 VAC	13W (14/20 I/O) / 20W (30/40/60 I/O)
Inrush Current	20 A for 8 ms at 120 VAC / 40 A for 8 ms at 240 VAC	30 A for 20 ms at 24 VDC
External Power Supply	Not provided (14/20 I/O) / 24 VDC, 300 mA (30/40/60 I/O)	Not provided
Insulation Resistance	20 MΩ min at 500 VDC (AC terminals to GR)	Not isolated between primary and secondary DC supplies
Dielectric Strength	2,300 VAC for 1 min (AC to GR), leakage ≤5 mA	Not isolated between primary and secondary DC supplies
Power Interrupt Time	10 ms min	2 ms min
Ambient Operating Temperature	-20°C to 60°C
Ambient Humidity	10% to 90%
Atmosphere	No corrosive gas
Ambient Storage Temperature	-20°C to 75°C (excluding battery)
Altitude	2,000 m max
Pollution Degree	2 or less (IEC61010-2-201)
Noise Resistance	2 kV on power supply line (IEC61000-4-4)
Overvoltage Category	Category II (IEC61010-2-201)
EMC Immunity Level	Zone B
Vibration Resistance	5 to 8.4 Hz: 3.5-mm amplitude; 8.4 to 150 Hz: 9.8 m/s² acceleration for 100 min in X, Y, Z (IEC60068-2-6)
Shock Resistance	147 m/s², 3 times in X, Y, Z (IEC60068-2-27)

I/O Configuration: Models CP2E-N20DR-D (20 I/O, relay output), CP2E-N40DR-D (40 I/O, relay output), and CP2E-N60DT-A (60 I/O, transistor output) offer flexible digital control.
Power Supply Options: AC models (suffix -A) accept 100-240 VAC; DC models (suffix -D) run on 24 VDC, with inrush current protection for reliable startup.
Environmental Robustness: Operates from -20°C to 60°C, withstands 2 kV noise immunity, and meets IEC standards for vibration and shock resistance—ideal for factory floors.
Compact Footprint: Dimensions as low as 90mm × 80mm × 86mm for 14/20 I/O units, saving valuable panel space.
Built-in Safety: Overvoltage Category II and pollution degree 2 compliance ensure safe installation in industrial control cabinets.
