The ABB CI531-EIP is a versatile S500 interface module engineered to bridge distributed I/O with EtherNet/IP networks. As an EtherNet/IP adapter, it provides a compact yet powerful solution for collecting and controlling field signals, featuring 4 analog inputs (voltage, current, and RTD), 2 analog outputs (voltage and current), 8 digital inputs at 24 VDC, and 8 digital outputs rated at 24 VDC/0.5 A. Designed for seamless integration into ABB’s distributed automation architecture, this module ensures low-latency data exchange and simplifies wiring in complex industrial setups. Its lightweight, space-saving form factor (0.136 kg, 67.5 x 76 x 62 mm) makes it ideal for panel mounting in tight enclosures, while its robust construction guarantees long-term reliability in demanding environments.
| Specification |
Details |
| Product Type |
S500 Interface Module – EtherNet/IP Adapter |
| Model Number |
CI531-EIP |
| Analog Inputs |
4 channels: voltage (U), current (I), RTD |
| Analog Outputs |
2 channels: voltage (U), current (I) |
| Digital Inputs |
8 channels, 24 VDC |
| Digital Outputs |
8 channels, 24 VDC, 0.5 A per channel |
| Fieldbus Protocol |
EtherNet/IP (adapter mode) |
| Power Supply |
24 VDC (via S500 bus or external) |
| Product Net Weight |
0.136 kg |
| Product Net Depth / Length |
62 mm |
| Product Net Height |
76 mm |
| Product Net Width |
67.5 mm |
| Gross Weight (packaged) |
0.16 kg |
| Package Level 1 Dimensions (L x H x W) |
84 mm x 72 mm x 71 mm |
| Package Level 1 Units |
1 carton |
| Product Main Type |
CI531 |
| Product Name |
Distributed Automation I/Os |
| eClass |
27-24-26-07 |
| ETIM 8 |
EC001604 – Fieldbus, decentr. periphery - communication module |
| UNSPSC |
32151705 |
| Minimum Order Quantity |
1 piece |
| Order Multiple |
1 piece |
| Selling Unit of Measure |
piece |
| Made To Order |
No (stock item) |
