Yaskawa SGMJV-04AAA41 Servo Motor 400W

Series#: Yaskawa

Product Details

YASKAWA SERVO MOTOR 400W SGMJV-04AAA41: High-performance AC servo motor designed for precision motion control in industrial automation.
Rated output of 400W (0.4 kW) with a compact, lightweight frame for space-constrained applications.
Equipped with a high-resolution 20-bit incremental encoder for exceptional positioning accuracy and smooth low-speed operation.
Built-in electromagnetic brake option for holding torque during power-off conditions, enhancing safety in vertical axis applications.
Compatible with Yaskawa Sigma-5 and Sigma-7 series servo drives for seamless integration and optimal performance.
Rated speed of 3000 min⁻¹ and maximum speed of 6000 min⁻¹, delivering high dynamic response for demanding motion profiles.
100% Genuine and New, rigorously inspected before international dispatch.

Specification

The YASKAWA SERVO MOTOR 400W SGMJV-04AAA41 is a robust and precise rotary servo motor from the acclaimed Sigma-5 family, engineered to meet the rigorous demands of modern industrial automation systems. This motor features a 400W rated output with a rated torque of 1.27 Nm and a stall torque of 1.27 Nm, providing consistent power delivery for applications such as pick-and-place robots, packaging machinery, and CNC tool changers. The SGMJV-04AAA41 incorporates a 20-bit absolute or incremental encoder (depending on configuration) for high-resolution feedback, ensuring minimal positioning error and exceptional velocity stability. Its IP67-rated enclosure (with connector) offers protection against dust and water ingress, making it suitable for harsh manufacturing environments. The motor is designed for 200V AC input and operates with a maximum current of 2.9 A, delivering smooth performance across a wide speed range from 0 to 6000 min⁻¹. The built-in electromagnetic brake (standard on this model) provides reliable holding torque of 1.2 Nm, ideal for vertical load applications. Below is a detailed specification table for the YASKAWA SERVO MOTOR 400W SGMJV-04AAA41.

Parameter	Specification
Model	YASKAWA SERVO MOTOR 400W SGMJV-04AAA41
Rated Output Power	400 W (0.4 kW)
Rated Torque	1.27 Nm
Stall Torque	1.27 Nm
Rated Speed	3000 min⁻¹
Maximum Speed	6000 min⁻¹
Rated Current	2.0 A (RMS)
Maximum Current	2.9 A (RMS)
Power Supply Voltage	200 V AC (single-phase or three-phase, depending on drive)
Encoder Type	20-bit incremental encoder (standard; absolute encoder optional)
Encoder Resolution	1,048,576 pulses/rev (20-bit)
Electromagnetic Brake	Built-in (holding torque: 1.2 Nm)
Brake Power Supply	24 V DC ±10%
Insulation Class	Class F (155°C)
Protection Rating	IP67 (with connector, excluding shaft seal)
Ambient Temperature	0 to 40°C (operation)
Ambient Humidity	20% to 80% RH (non-condensing)
Vibration Resistance	24.5 m/s² (2.5 G) at 10-200 Hz
Mounting Orientation	Horizontal or vertical (with brake)
Weight (with brake)	Approx. 1.6 kg
Shaft Type	Straight shaft with keyway (standard)
Shaft Diameter	14 mm
Connector Type	Standard round connector (power and encoder)
Compatible Drives	Yaskawa Sigma-5 (SGDV series) or Sigma-7 (SGD7S series)
Application Examples	Pick-and-place robots, packaging machines, CNC tool changers, conveyor systems
