The Mitsubishi HMI Touch Screen GT1030-LBL/LWL/HBL/HWL is a rugged, high-reliability operator interface from the GOT1000 series, engineered for demanding machine control applications. This 4.5-inch monochrome unit delivers exceptional readability with its STN LCD, adjustable contrast (16 levels) and intensity (8 levels), and a long-life LED backlight rated for approximately 50,000 hours. Designed for seamless integration, it supports 50 programmable touch keys, robust data storage via flash and SRAM, and a dedicated RS-232 port for PC communication. The GT1030-LBL/LWL/HBL/HWL is a cost-effective solution for HMI tasks requiring durability, simplicity, and proven performance in compact panel spaces.
| Parameter |
Specification |
| Display Type |
STN monochrome (white/black) liquid crystal |
| Screen Size |
4.5″ |
| Resolution |
288 x 96 dots (horizontal format) |
| Display Area |
W109.42 x H35.98 mm (4.3 x 1.41 inches) |
| Display Characters |
16-dot font: 36 chars x 6 lines; 12-dot font: 48 chars x 8 lines (horizontal) |
| Display Colors |
Monochrome (white/black) |
| Viewing Angle |
Left/Right: 30°, Top: 20°, Bottom: 30° (horizontal) |
| Contrast Adjustment |
16-level |
| Intensity Adjustment |
8-level |
| LCD Intensity |
200 cd/m² (in green) |
| Backlight Life |
Approx. 50,000 h (to 1/5 intensity at 25°C) |
| Backlight |
LED, 3 colors (green, red, orange), no replacement required; PLC controllable |
| Touch Panel |
Matrix resistive film; max 50 keys/screen |
| Key Size (Min.) |
16 x 16 dots |
| 2-Point Press |
Enable |
| Touch Life |
1 million+ times (0.98N max force) |
| Memory C Drive |
Flash memory (internal), 1.5 MB max for project data and OS |
| Write Life (C Drive) |
100,000 times |
| D Drive |
SRAM (internal) for alarm history, recipe data, time action settings |
| Battery |
GT11-50BAT lithium battery |
| Backup Targets |
Clock, alarm history, recipe data, time action settings |
| Battery Life |
Approx. 5 years (at 25°C) |
| PC Communication |
RS-232 1ch; speed: 115,200/57,600/38,400/19,200/9,600/4,800 bps; connector: MINI DIN 6-pin female; for project upload/download, OS install, transparent function |
| Buzzer Output |
Single tone (LONG/SHORT/OFF adjustable) |
| Protective Structure |
Equivalent to IP67 (front section, horizontal format) |
- Display Performance: STN monochrome LCD with 288 x 96 resolution ensures crisp text and graphics in low-light or high-ambient conditions.
- Backlight Flexibility: Tri-color LED backlight (green, red, orange) supports status indication and screensaver control via PLC, eliminating lamp replacement.
- Touch Panel Reliability: Matrix resistive design rated for over 1 million presses, with 2-point press enable for multi-touch gestures.
- Data Storage: 1.5 MB flash memory for project files and OS; SRAM for critical runtime data with lithium battery backup for up to 5 years.
- Communication Interface: RS-232 port with up to 115,200 bps for fast programming and transparent monitoring.
- Environmental Durability: IP67-equivalent front panel protection against dust and water ingress, suitable for washdown or dusty factory floors.
- Buzzer Feedback: Configurable single-tone buzzer for touch key confirmation, enhancing operator interaction.
