Mitsubishi GT1030-LBLW Touch Screen HMI

Series#: Mitsubishi

Product Details

Model: Mitsubishi HMI Touch screen GT1030-LBLW/LWLW/HBLW/HWLW – compact 4.5-inch monochrome operator interface.
STN monochrome (white/black) LCD with LED backlight offering 3 selectable colors (white, red, pink).
288 x 96 pixel resolution in horizontal format for clear data display.
Matrix resistive touch panel supports up to 50 keys per screen with 2-point press capability.
Built-in flash memory (1.5 MB) for project data and SRAM for alarm/recipe storage.
Rugged design with 50,000-hour backlight life and 1 million-touch cycle durability.
Guaranteed 100% Original factory condition, offering fast and secure worldwide delivery.

Specification

The Mitsubishi HMI Touch screen GT1030-LBLW/LWLW/HBLW/HWLW is a high-reliability operator terminal designed for space-constrained industrial applications. Featuring a 4.5-inch STN monochrome display with a powerful LED backlight that can switch between white, red, and pink, this unit provides exceptional visibility in varying ambient light conditions. The resistive touch panel supports intuitive control with up to 50 programmable keys per screen, while the 288 x 96 dot resolution ensures crisp text and graphics. Ideal for machine builders seeking a cost-effective, durable HMI with a long operational life, the GT1030-LBLW/LWLW/HBLW/HWLW seamlessly integrates into Mitsubishi automation ecosystems.

Parameter	Specification
Display Type	STN monochrome (white/black) liquid crystal
Screen Size	4.5″
Resolution	288 x 96 dots (horizontal format)
Display Size	W109.42 x H35.98 mm (4.3 x 1.41 inches)
Display Characters	16-dot: 36 chars x 6 lines; 12-dot: 48 chars x 8 lines (horizontal)
Display Color	Monochrome (white/black)
Viewing Angle	Left/Right: 30°, Top: 20°, Bottom: 30° (horizontal)
Contrast Adjustment	16-level
Intensity Adjustment	8-level
LCD Intensity (White)	GT1030-LBLW/LWLW: 300 cd/m²; GT1030-HBLW/HWLW: 500 cd/m²
Backlight Life	Approx. 50,000 h (to 1/5 intensity at 25°C)
Backlight Type	LED, 3 colors (white, red, pink), no replacement required
Touch Panel	Matrix resistive film, max. 50 keys/screen
Key Size Min	16 x 16 dots per key
2-Point Press	Enabled
Touch Life	1 million times or more (0.98N max. force)
Memory C Drive	Flash memory (internal), 1.5 MB max. for project data & OS
Memory D Drive	SRAM (internal) for alarm history, recipe, time action
Write Life (C Drive)	100,000 times
Battery	GT11-50BAT lithium battery for clock & SRAM backup
Backup Target	Clock data, alarm history, recipe data, time action settings

Display Performance: STN monochrome LCD with 288x96 resolution ensures legible text and simple graphics in horizontal orientation, ideal for basic HMI tasks.
Backlight Versatility: LED backlight with 3 selectable colors (white, red, pink) and ON/BLINK/OFF control via PLC system information, enhancing operator feedback.
Touch Reliability: Matrix resistive panel rated for 1 million actuations with 2-point press support, suitable for frequent industrial use.
Data Integrity: 1.5 MB flash memory for project storage and SRAM for critical alarm/recipe data, backed by a lithium battery for up to 50,000 hours of clock retention.
Compact Form Factor: 4.5-inch diagonal display with minimal bezel, perfect for panel-mount installations in tight control cabinets.
