Mitsubishi AJ65SBTB2N-8A CC-Link Module

Series#: Mitsubishi

Product Details

Mitsubishi CC Link Module AJ65SBTB2N-8A and AJ65SBTB2N-16A – high-performance AC input modules for industrial automation.
8-point (AJ65SBTB2N-8A) and 16-point (AJ65SBTB2N-16A) AC input configurations for flexible system design.
Rated input voltage: 100-120 V AC, 50/60 Hz, with photocoupler isolation for reliable signal integrity.
Compact, lightweight design (0.2 kg for 8-point, 0.25 kg for 16-point) for easy integration into CC Link networks.
100% Original product. We provide efficient, traceable, and secure global shipping solutions.

Specification

The Mitsubishi CC Link Module series, including the AJ65SBTB2N-8A and AJ65SBTB2N-16A, delivers exceptional AC input handling for distributed control systems. These modules are engineered for seamless integration with CC Link networks, providing reliable 8-point or 16-point input capabilities with photocoupler isolation. Ideal for factory automation, they offer robust noise immunity and wide operating voltage ranges, ensuring stable operation in industrial settings. Each unit is 100% original and new, with fast shipping to support your project timelines.

Specification	AJ65SBTB2N-8A	AJ65SBTB2N-16A
Number of Input Points	8 points	16 points
Insulation Method	Photocoupler	Photocoupler
Rated Input Voltage	100 to 120 V AC 50/60 Hz	100 to 120 V AC 50/60 Hz
Rated Input Current	Approx. 7 mA (100 V AC 60 Hz)	Approx. 7 mA (100 V AC 60 Hz)
Operating Voltage Range	85 to 132 V AC (50/60 Hz ±5%)	85 to 132 V AC (50/60 Hz ±5%)
Max. Simultaneous Input Points	100% at 100 V AC, 60% at 132 V AC	100% at 100 V AC, 60% at 132 V AC
Inrush Current	Max. 200 mA within 1 ms (at 132 V AC)	Max. 200 mA within 1 ms (at 132 V AC)
ON Voltage/ON Current	80 V AC or higher/5 mA or higher	80 V AC or higher/5 mA or higher
OFF Voltage/OFF Current	30 V AC or lower/1 mA or lower	30 V AC or lower/1 mA or lower
Input Resistance	Approx. 15 kΩ (60 Hz), Approx. 18 kΩ (50 Hz)	Approx. 15 kΩ (60 Hz), Approx. 18 kΩ (50 Hz)
Number of Stations Occupied	1 station, 32 points assignment (use 8 points)	1 station, 32 points assignment (use 16 points)
I/O Module Power Supply	20.4 to 26.4 V DC (ripple ratio: within 5%)	20.4 to 26.4 V DC (ripple ratio: within 5%)
Withstand Voltage	1780 V AC between AC terminals and ground (rms/3 cycles, 2000 m above sea level); 500 V AC for 1 minute between DC terminals and ground	1780 V AC between AC terminals and ground (rms/3 cycles, 2000 m above sea level); 500 V AC for 1 minute between DC terminals and ground
Insulation Resistance	10 MΩ or higher (500 V DC tester) between AC/DC terminals and ground	10 MΩ or higher (500 V DC tester) between AC/DC terminals and ground
Weight (kg/lb.)	0.2 (0.44)	0.25 (0.55)
External Wiring System	7-point 2-piece terminal block (transmission circuit, module power supply), Direct-type 18-point terminal block (I/O power supply area) (M3 screw)	7-point 2-piece terminal block (transmission circuit, module power supply), Direct-type 34-point terminal block (I/O power supply area) (M3 screw)
Applicable Solderless Terminal	RAV1.25-3.5, V2-MS3, RAP2-3S, RAP2-3SL, 2-3N, 2-3S (wire size: 0.3 to 2.0 mm²)	RAV1.25-3.5, V2-MS3, RAP2-3S, RAP2-3SL, 2-3N, 2-3S (wire size: 0.3 to 2.0 mm²)

Technical Deep Dive:

Isolation and Noise Immunity: Both modules use photocoupler isolation with a withstand voltage of 1780 V AC (AC terminals to ground) and 500 V AC (DC terminals to ground). Noise durability includes simulator noise up to 1500 Vp-p and fast transient/burst per IEC61000-4-4 at 1 kV.
Operating Conditions: Rated input voltage of 100-120 V AC with a wide operating range of 85-132 V AC. The modules support 100% simultaneous ON at 100 V AC, with derating to 60% at 132 V AC, ensuring stable operation under varying loads.
Connector and Wiring: The 8-point module uses a 18-point terminal block, while the 16-point module uses a 34-point terminal block, both with M3 screws. Applicable solderless terminals include RAV1.25-3.5, V2-MS3, and others for wire sizes from 0.3 to 2.0 mm².
Power Supply: I/O module power supply range is 20.4 to 26.4 V DC with a ripple ratio within 5%, ensuring reliable internal circuitry operation.
Physical Design: The AJ65SBTB2N-8A weighs 0.2 kg and the AJ65SBTB2N-16A weighs 0.25 kg, both compact for easy mounting in CC Link racks.
