Mitsubishi MR-J2S Servo Drive 5kW MR-J2S-500B

Series#: Mitsubishi

Product Details

Mitsubishi MR-J2S-500B – High-performance 5kW servo drive for precision motion control.
Sine-wave PWM control with current control system ensures smooth, accurate torque and speed regulation.
Built-in dynamic brake for rapid, safe deceleration in emergency stops.
Comprehensive safety features: overcurrent, overload, overvoltage, encoder fault, and regeneration protection.
Supports maximum command input of 10 Mpps for high-speed positioning applications.
Fan-cooled, open IP00 enclosure designed for industrial environments up to 55°C.
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

The Mitsubishi MR-J2S-500B is a robust 5 kW servo drive engineered for demanding industrial automation tasks. As part of the renowned MR-J2S series, this amplifier delivers exceptional performance with sine-wave PWM control and a current control system, ensuring precise torque and speed output. The MR-J2S-500B features a built-in dynamic brake for reliable emergency stops and a comprehensive suite of protective functions including overcurrent, overload, overvoltage, and encoder fault detection. With a maximum command input of 10 Mpps, it excels in high-speed positioning applications. The unit operates on a 3-phase 200 to 230 VAC main circuit supply, with a fan-cooled open IP00 enclosure suitable for ambient temperatures from 0 to 55°C. This model is 100% original, factory-new, and available for immediate dispatch.

Parameter	Specification (MR-J2S-500B)
Model	MR-J2S-500B
Rated Output	5 kW
Control System	Sine-wave PWM control / Current control system
Main Circuit Power Supply	3-phase 200 to 230 VAC, 50/60 Hz
Permissible Voltage Fluctuation (Main)	170 to 253 VAC
Permissible Frequency Fluctuation	±5% max
Control Circuit Power Supply	1-phase 200 to 230 VAC, 50/60 Hz
Control Circuit Voltage Fluctuation	170 to 253 VAC
Control Circuit Frequency Fluctuation	±5% max
Power Consumption	50 W
Dynamic Brake	Built-in
Protective Functions	Overcurrent, regeneration overvoltage, overload (electronic thermal), motor overheat, encoder fault, regeneration fault, undervoltage/sudden power outage, overspeed, excess error
Max Command Input (Position Control)	Approximately 10 Mpps
Structure	Fan cooling, open (IP00)
Ambient Temperature	0 to 55°C (32 to 131°F) operating; –20 to 65°C (–4 to 149°F) storage
Ambient Humidity	90% RH max (non-condensing) operating and storage
Atmosphere	Indoors (no direct sunlight); free from corrosive gas, flammable gas, oil mist, dust
Elevation	1000 m (3280 ft) or less above sea level
Vibration Resistance	5.9 m/s² max
Mass	4.9 kg (10.8 lb)
