Panasonic Servo Motor MINAS A4 400W MHMD042P1S

Series#: Panasonic

Product Details

PANASONIC SERVO MOTOR MINAS A4 400W MHMD042P1S – high-performance, compact AC servo motor for precision motion control.
Rated output of 400W with a rated torque of 1.3 Nm and maximum torque of 3.8 Nm, ensuring robust and responsive operation.
Equipped with a 17-bit absolute encoder (131,072 ppr) for high-resolution position feedback and smooth low-speed control.
Designed for 200V AC input, featuring a rated speed of 3000 rpm and a maximum speed of 5000 rpm for dynamic applications.
Compact flange size (60 mm square) with IP65 protection rating, ideal for harsh industrial environments.
Direct replacement for legacy MINAS A4 series systems, ensuring seamless integration with existing drives and controllers.
Guaranteed 100% Original factory condition, offering fast and secure worldwide delivery.

Specification

The PANASONIC SERVO MOTOR MINAS A4 400W MHMD042P1S is a cornerstone of the MINAS A4 family, engineered for demanding automation tasks such as packaging, robotics, and CNC machinery. This motor integrates a high-resolution 17-bit absolute encoder to deliver exceptional position accuracy and repeatability, even at low speeds. Its robust 400W output, combined with a peak torque of 3.8 Nm, ensures reliable performance under variable loads. The motor is optimized for 200V AC systems and features a compact 60 mm flange design, making it suitable for space-constrained installations. With an IP65 rating, it withstands dust and water ingress, while the standard keyway shaft provides direct coupling flexibility. The MHMD042P1S is a perfect upgrade or replacement within the MINAS A4 ecosystem, offering long-term reliability and energy efficiency.

Parameter	Specification
Model	PANASONIC SERVO MOTOR MINAS A4 400W MHMD042P1S
Series	MINAS A4
Rated Output Power	400 W
Rated Torque	1.3 Nm
Maximum Torque	3.8 Nm
Rated Speed	3000 rpm
Maximum Speed	5000 rpm
Power Supply Voltage	AC 200 V (3-phase or single-phase)
Encoder Type	17-bit absolute encoder (131,072 ppr)
Encoder Resolution	131,072 pulses per revolution
Flange Size	60 mm square (standard)
Shaft Type	Keyway shaft with parallel key (standard)
Shaft Diameter	14 mm (with keyway)
Protection Rating	IP65 (excluding shaft seal)
Insulation Class	Class B (130°C)
Rated Current	Approx. 2.5 A (at rated torque)
Moment of Inertia	0.25 x 10^-4 kg·m²
Brake Option	No brake (standard model; brake available as optional)
Weight	Approx. 1.6 kg
Operating Temperature Range	0°C to +40°C (ambient)
Storage Temperature Range	-20°C to +60°C
Vibration Resistance	10 to 55 Hz, 0.15 mm amplitude
Connector Type	Standard 20-pin connector (for encoder and power)
Compatible Drive	MINAS A4 series AC servo drives (e.g., MCDHT3520, MCDKT3520)
