Mitsubishi MR-J2S-60B Servo Drive

Series#: Mitsubishi

Product Details

MR-J2S-60B MITSUBISHI ELECTRIC servo drive, designed for high-precision motion control in industrial automation systems.
Rated output of 0.6 kW, ideal for medium-load applications such as packaging, robotics, and CNC machinery.
Built-in advanced real-time auto-tuning function for optimal performance without manual adjustments.
Supports high-speed communication via SSCNET II network, enabling synchronized multi-axis control.
Compact design with IP20 protection, suitable for panel mounting in harsh industrial environments.
Compatible with a wide range of MITSUBISHI ELECTRIC servo motors for flexible system integration.
Guaranteed 100% Original factory condition, offering fast and secure worldwide delivery.

Specification

The MR-J2S-60B MITSUBISHI ELECTRIC servo amplifier is a cornerstone component for modern automation solutions, delivering exceptional torque control and speed regulation. Engineered for demanding industrial tasks, this drive integrates seamlessly into existing systems, leveraging SSCNET II for fast data exchange and precise positioning. Its robust construction ensures long-term reliability, while the auto-tuning feature minimizes setup time, making it a preferred choice for engineers seeking efficiency and accuracy in motion control applications.

Parameter	Specification
Model	MR-J2S-60B
Rated Output Power	0.6 kW
Rated Input Voltage	3-Phase AC 200-230V, 50/60 Hz
Rated Input Current	4.0 A
Rated Output Current	3.0 A
Control Method	Sine-wave PWM, current control
Communication Interface	SSCNET II (High-speed serial bus)
Position Feedback Resolution	131072 pulses/rev (17-bit encoder compatible)
Speed Control Range	1:5000 (with rated torque)
Frequency Response	Up to 600 Hz
Protection Class	IP20
Operating Temperature	0°C to 55°C (ambient)
Storage Temperature	-20°C to 65°C
Humidity	5% to 90% RH (non-condensing)
Weight	Approximately 1.2 kg
Dimensions (W x H x D)	60 mm x 170 mm x 150 mm
Compatible Motor Series	HC-SFS, HC-RFS, HC-UFS series motors
