The Siemens SIMATIC DP electronic module 6ES7134-4MB02-0AB0 is a high-feature analog input module designed specifically for the ET 200S distributed I/O system. This module provides two analog input channels for current signals, offering exceptional accuracy and diagnostic depth for demanding industrial automation applications. With its enhanced feature set, including wire-break detection, overload protection, and channel-specific configuration via hardware or software, the 6ES7134-4MB02-0AB0 ensures reliable signal acquisition in harsh environments. It connects directly to the ET 200S backplane bus and supports both standard and high-speed data exchange with Siemens controllers. Ideal for process monitoring, machine control, and safety-critical loops, this module is a cornerstone of modern plant automation.
| Parameter |
Specification |
| Product Type |
SIMATIC DP, Electronic Module for ET 200S |
| Model Number |
6ES7134-4MB02-0AB0 |
| Number of Analog Inputs |
2 channels (current signals) |
| Input Signal Range |
0 to 20 mA, 4 to 20 mA (selectable per channel) |
| Resolution |
16 bits (including sign) |
| Conversion Time |
Typical 2 ms per channel |
| Diagnostics |
Wire-break detection, short-circuit monitoring, overrange/underrange |
| Parameterization |
Channel-specific via hardware configuration or TIA Portal |
| Backplane Bus Interface |
Integrated, compatible with ET 200S interface modules (e.g., IM 151-1) |
| Supply Voltage |
Via backplane bus (24 V DC typical) |
| Power Consumption |
Typically 1.5 W (max) |
| Operating Temperature |
0 °C to +60 °C (horizontal mounting) |
| Storage Temperature |
-40 °C to +85 °C |
| Dimensions (W x H x D) |
15 mm x 76 mm x 55 mm (approx.) |
| Weight |
Approximately 30 g |
| Protection Class |
IP20 (for use in control cabinet) |
| Certifications |
CE, UL, cUL, FM (for hazardous locations) |
| Compatibility |
Siemens S7-300, S7-400, S7-1500 via ET 200S DP/PN; TIA Portal V13 or higher |
