The SIEMENS 6ES7153-2BA10-0XB0, also known as the IM 154-8FX PN/DP CPU, is a high-performance interface module and CPU combination for the ET200PRO distributed I/O family. This unit integrates a powerful CPU with both PROFINET (PN) and PROFIBUS DP (DP) interfaces, enabling seamless connectivity in mixed-protocol industrial networks. Designed for decentralized control in demanding environments, it supports up to 125 DP slaves and provides fast data exchange via PROFINET IRT. The module is fully compatible with SIMATIC STEP 7 and TIA Portal engineering tools, ensuring straightforward configuration and diagnostics. Its rugged metal housing and IP65/67 protection make it ideal for on-machine or field-mounted applications where space is limited but reliability is critical.
| Specification |
Details |
| Product Type |
SIMATIC DP Interface Module + CPU for ET200PRO |
| Model Designation |
6ES7153-2BA10-0XB0 / IM 154-8FX PN/DP |
| Interfaces |
1 x PROFINET (RJ45), 1 x PROFIBUS DP (D-sub 9-pin female) |
| PROFINET Protocol |
IRT (Isochronous Real-Time), RT, TCP/IP |
| PROFIBUS DP Support |
DP-V0, DP-V1, DP-V2 (master class 1) |
| Max. Number of DP Slaves |
125 |
| Integrated CPU Performance |
Approx. 0.1 ms per 1k instructions (binary), 32 KB work memory |
| Power Supply Voltage |
24 V DC (via ET200PRO backplane bus or external connector) |
| Current Consumption (typ.) |
0.4 A (from backplane bus) |
| Power Dissipation (typ.) |
9 W |
| Operating Temperature Range |
-25 °C to +60 °C (horizontal mounting); -25 °C to +50 °C (vertical) |
| Protection Class |
IP65/67 (when installed in suitable enclosure) |
| Dimensions (W x H x D) |
60 mm x 125 mm x 75 mm (approx.) |
| Weight |
Approx. 200 g |
| Diagnostics |
LED indicators for bus status, fault, and power; integrated diagnostics via PROFINET/PROFIBUS |
| Engineering Software |
STEP 7 V5.5+ or TIA Portal V13 SP1+ |
| Compatible I/O Systems |
ET200PRO (all standard and fail-safe modules) |
| Certifications |
CE, cULus, ATEX (Zone 2/22), FM (Class I, Div. 2) |
