The SIEMENS SIMATIC DP ET 200S electronics module, model 6ES7134-4GB61-0AB0, is a high-performance 4-channel analog input module designed for distributed automation systems. This module excels in capturing precise analog signals from sensors and transmitters, converting them into digital values for processing by the ET 200S interface module. With its robust electrical isolation and support for multiple signal types, it is ideal for demanding applications in manufacturing, process control, and material handling. The 6ES7134-4GB61-0AB0 module ensures reliable data acquisition in harsh industrial settings, backed by Siemens' proven engineering and global support network.
| Specification |
Details |
| Product Type |
SIMATIC DP ET 200S Electronics Module |
| Model Number |
6ES7134-4GB61-0AB0 |
| Number of Analog Inputs |
4 (4 AI) |
| Input Signal Types (Voltage) |
±10 V, 0-10 V, ±5 V, 0-5 V, ±2.5 V, 0-2.5 V |
| Input Signal Types (Current) |
±20 mA, 0-20 mA, 4-20 mA |
| Resolution |
15 bits + sign (16 bits total) |
| Conversion Time per Channel |
Approximately 1 ms (typical) |
| Isolation |
Electrical isolation between channels and backplane bus (500 V AC) |
| Operating Voltage |
24 V DC (from ET 200S backplane) |
| Power Consumption |
Typically 1.2 W (from backplane) |
| Connection Type |
Screw-type terminals (removable) |
| Backplane Bus Interface |
PROFIBUS DP via ET 200S interface module |
| Diagnostics |
Group diagnostics, wire-break detection (for current signals) |
| Ambient Temperature (Operating) |
0 °C to +60 °C |
| Ambient Temperature (Storage) |
-40 °C to +85 °C |
| Dimensions (W x H x D) |
Approximately 15 mm x 110 mm x 75 mm (module only) |
| Weight |
Approximately 40 g |
| Standards |
IEC 61131-2, CE, UL, cUL |
| Compatible Interface Modules |
ET 200S IM 151 series (e.g., 6ES7151-1AA06-0AB0) |
| Shipping Condition |
Factory-sealed, 100% Original and New, ready for global shipment |
