The SIEMENS SIMATIC DP Electronics Module 6ES7134-4GB01-0AB0 is a high-performance analog input module designed exclusively for the ET200S distributed I/O system. This module excels in converting standard 4-20mA current signals from field sensors (such as pressure, flow, or temperature transmitters) into digital values for the PLC controller. With its 2-channel architecture, it provides simultaneous measurement with 15-bit resolution plus sign, ensuring precise data acquisition even in demanding applications. The module's galvanic isolation protects against ground loops and electrical noise, while its compact form factor integrates seamlessly into ET200S stations. Whether used in chemical plants, automotive assembly lines, or water treatment facilities, the 6ES7134-4GB01-0AB0 delivers consistent performance and long-term reliability. Below are the detailed technical specifications derived from Siemens' official product documentation.
| Specification |
Details |
| Product Type |
SIMATIC DP, Electronics Module for ET200S |
| Model Number |
6ES7134-4GB01-0AB0 |
| Input Channels |
2 analog inputs (differential or single-ended, configurable) |
| Input Signal Type |
4-20 mA (current) |
| Resolution |
15 bits + sign (16-bit total) |
| Measurement Principle |
Sigma-delta conversion |
| Conversion Time |
Typical 2 ms per channel (all channels simultaneously) |
| Maximum Input Current |
25 mA (overload protection) |
| Input Impedance |
250 ohms (typical) |
| Galvanic Isolation |
Yes, between channels and backplane bus; 500 V AC (test voltage) |
| Common Mode Rejection |
> 80 dB at 50/60 Hz |
| Normal Mode Rejection |
> 40 dB at 50/60 Hz |
| Linearity Error |
±0.05% of full scale (typical) |
| Temperature Drift |
±0.01% / °C (typical) |
| Operating Voltage |
24 V DC via ET200S backplane bus (powered by interface module) |
| Current Consumption (from backplane bus) |
Max 30 mA |
| Power Dissipation |
Typical 0.7 W |
| Diagnostics |
Group diagnostics via LED (green/red), channel-specific diagnostics via software |
| LED Indicators |
1 green LED for power/status; 1 red LED for diagnostics |
| Configuration |
Via STEP 7 (V5.x or TIA Portal) – parameter assignment for measurement range, filter, and diagnostics |
| Dimensions (W x H x D) |
15 mm x 81 mm x 52 mm (standard ET200S module width) |
| Weight |
Approx. 30 g |
| Ambient Temperature (Operation) |
-25°C to +60°C |
| Ambient Temperature (Storage) |
-40°C to +85°C |
| Relative Humidity |
5% to 95% (non-condensing) |
| Protection Class |
IP20 (in enclosure) |
| Standards & Approvals |
CE, UL, cULus, FM Class I Div 2 (hazardous area), ATEX (Zone 2) – depending on system configuration |
| Compatible Systems |
ET200S (with IM151-1 or IM151-3 interface modules); PROFIBUS DP or PROFINET |
| Ordering Information |
6ES7134-4GB01-0AB0 (single module, no accessories included) |
