The SIEMENS 6ES7134-4FB01-0AB0 is a high-performance SIMATIC DP electronics module specifically designed for the ET 200S distributed I/O system. This analog input module provides four channels for 2-wire transmitters, handling standard 0/4-20 mA current signals with exceptional accuracy and stability. Engineered for industrial environments, it integrates seamlessly with PROFIBUS DP networks, offering real-time diagnostics and parameterization. The module's compact form factor and robust construction ensure reliable operation in space-constrained control cabinets, making it ideal for process automation, manufacturing, and material handling applications. With a rated supply voltage of 24 V DC and built-in short-circuit protection, the 6ES7134-4FB01-0AB0 delivers consistent performance and longevity in mission-critical systems.
| Parameter |
Specification |
| Product Type |
SIMATIC DP Electronics Module for ET 200S |
| Model Number |
6ES7134-4FB01-0AB0 |
| Input Channels |
4 analog inputs (2-wire transmitters) |
| Input Signal Range |
0 to 20 mA / 4 to 20 mA (selectable) |
| Resolution |
11 bits plus sign |
| Supply Voltage |
24 V DC (20.4 to 28.8 V DC) |
| Current Consumption (from backplane bus) |
Typical 20 mA |
| Power Loss |
Typical 1.5 W |
| Communication Interface |
PROFIBUS DP (via ET 200S interface module) |
| Diagnostics |
Integrated (wire break, short circuit, parameter error) |
| Galvanic Isolation |
Yes, between channels and backplane bus |
| EMC Immunity |
EN 61000-6-2, EN 61000-6-4 |
| Operating Temperature |
0 °C to +60 °C |
| Storage Temperature |
-40 °C to +85 °C |
| Relative Humidity |
5% to 95% (non-condensing) |
| Dimensions (W x H x D) |
15 mm x 81 mm x 52 mm (module only) |
| Weight |
Approx. 50 g |
| Protection Class |
IP20 |
| Certifications |
CE, cULus, ATEX (for use in Zone 2) |
