The SIEMENS SIMATIC DP electronic module 6ES7132-4HB01-0AB0 is a critical component for ET 200S distributed I/O systems, designed to deliver reliable digital output control in demanding automation environments. This module offers 5 digital outputs with 24V DC and 2A per channel, ensuring robust switching for actuators, valves, and indicators. Its PROFIBUS DP interface enables high-speed data exchange with central controllers, while the compact footprint and spring-loaded terminals simplify field installation. Engineered for longevity, the 6ES7132-4HB01-0AB0 includes diagnostic LEDs and short-circuit protection, making it ideal for manufacturing, process control, and logistics applications.
| Parameter |
Specification |
| Product Type |
SIMATIC DP Electronic Module for ET 200S |
| Model Number |
6ES7132-4HB01-0AB0 |
| Output Type |
Digital, 5 channels |
| Output Voltage |
24V DC (nominal) |
| Output Current per Channel |
2A (max) |
| Total Output Current (all channels) |
10A (max, with proper derating) |
| Short-Circuit Protection |
Yes, electronic (automatic restart) |
| Overload Protection |
Yes, thermal |
| Communication Interface |
PROFIBUS DP (via ET 200S interface module) |
| Diagnostic Functions |
LED indicators for channel status, group fault, and bus communication |
| Electrical Isolation |
Between channels and backplane bus: 500V AC |
| Supply Voltage |
24V DC (from backplane bus, ±20%) |
| Power Consumption |
Typical 1.5W (without load) |
| Operating Temperature |
0°C to +60°C (horizontal mounting), 0°C to +50°C (vertical mounting) |
| Storage Temperature |
-40°C to +85°C |
| Relative Humidity |
5% to 95% (non-condensing) |
| Protection Class |
IP20 (per EN 60529) |
| Dimensions (W x H x D) |
15mm x 81mm x 52mm (module only) |
| Weight |
Approx. 40g |
| Mounting Method |
Plug-in on ET 200S terminal module (e.g., 6ES7193-4CD30-0AA0) |
| Standards Compliance |
CE, UL, cUL, CSA, IEC 61131-2 |
