Engineered for demanding distributed control applications, the Siemens SIMATIC DP electronic module 6ES7132-4BD31-0AA0 delivers reliable 24V DC digital output switching for up to 5 channels in the ET 200S family. This module is a direct replacement for legacy units and offers enhanced diagnostic capabilities, including per-channel short-circuit detection and wire-break monitoring. With a rated output current of 2A per channel (resistive load) and integrated suppression diodes, it ensures stable operation in motor control, valve actuation, and signaling tasks. The module mounts directly onto an ET 200S terminal block (e.g., 6ES7193-4CB30-0AA0) and supports hot-swapping without system downtime. Its compact footprint (15mm wide) saves valuable cabinet space, while the IP20 protection rating allows use in clean industrial environments. Backed by Siemens’ rigorous quality standards, this module is ideal for automotive, chemical, and packaging industries requiring high cycle rates and minimal maintenance.
| Specification |
Details |
| Product Type |
SIMATIC DP Electronic Module for ET 200S |
| Model Number |
6ES7132-4BD31-0AA0 |
| Output Channels |
5 digital outputs (24V DC, 2A per channel) |
| Output Type |
Solid-state, short-circuit proof, overload protected |
| Rated Supply Voltage |
24V DC (20.4V to 28.8V) |
| Output Current per Channel |
2A (resistive load), 0.5A (inductive load) |
| Total Output Current (Module) |
10A (max, all channels active) |
| Switching Frequency |
100 Hz (resistive), 2 Hz (inductive) |
| Diagnostics |
Per-channel short-circuit, wire-break, and overload indication via LED |
| Protection Class |
IP20 (enclosed) |
| Operating Temperature |
-25°C to +60°C (storage: -40°C to +85°C) |
| Dimensions (W x H x D) |
15mm x 76mm x 80mm (approx.) |
| Weight |
Approx. 50g |
| Compatibility |
ET 200S interface modules (e.g., 6ES7151-1AA06-0AB0) and PROFIBUS DP/PROFINET networks |
| Certifications |
CE, UL, cUL, ATEX (Zone 2), IECEx |
| Warranty |
Standard 12 months (extended available) |
