The Siemens 6ES7132-4BD01-0AA0 is a SIMATIC DP electronic module specifically designed for the ET 200S distributed I/O system. This module serves as a digital output interface, enabling precise control of actuators and indicators in industrial automation processes. As part of the ET 200S family, it offers modularity and flexibility, allowing engineers to configure I/O points according to specific application needs. With its robust design and compatibility with PROFIBUS-DP networks, the 6ES7132-4BD01-0AA0 ensures reliable data exchange and minimal latency, making it ideal for high-speed manufacturing lines, packaging systems, and material handling operations. Each unit contains 5 electronic modules, optimizing space utilization in control cabinets while maintaining high signal integrity. The module supports hot-swapping for reduced maintenance downtime and is certified for use in demanding industrial environments.
| Parameter |
Specification |
| Product Type |
SIMATIC DP Electronic Module for ET 200S |
| Model Number |
6ES7132-4BD01-0AA0 |
| Number of Channels |
2 (per module, 5 modules per unit) |
| Output Type |
Digital, 24 V DC |
| Rated Supply Voltage |
24 V DC (20.4 to 28.8 V) |
| Output Current per Channel |
0.5 A |
| Total Output Current per Module |
1.0 A |
| Short-Circuit Protection |
Yes, electronic |
| Diagnostics |
Yes, via PROFIBUS-DP |
| Isolation |
Yes, between channels and backplane bus |
| Operating Temperature |
0 °C to +60 °C |
| Storage Temperature |
-40 °C to +85 °C |
| Relative Humidity |
Up to 95% (non-condensing) |
| Protection Class |
IP20 |
| Dimensions (W x H x D) |
15 mm x 81 mm x 52 mm (per module) |
| Weight |
Approx. 30 g per module |
| Certifications |
CE, cULus, ATEX (for hazardous areas) |
| Compatibility |
ET 200S interface modules (e.g., IM 151-1, IM 151-3) |
| Communication Protocol |
PROFIBUS-DP (DP-V0, DP-V1) |
| Power Consumption |
Typical 1.5 W per module (at 24 V DC) |
| Connection Type |
Spring-loaded terminals (push-in) |
