Mitsubishi FX5-32ET/DSS PLC Controller Module

Series#: Mitsubishi

Product Details

Model: Mitsubishi PLC Controller Module FX5-32ET/DSS and FX5-32ET/ESS – high-performance I/O modules for MELSEC iQ-F series.
Supports up to 256 local I/O points and 384 remote I/O points, with a total system capacity of 512 points.
Ultra-fast processing: LD X0 and MOV D0 D1 instructions executed in just 34 ns.
Large program memory: 64 k steps (128 kbytes) with 120 kbytes device/label memory and 5 Mbytes data memory.
Versatile programming languages: Ladder Diagram, Structured Text, and Function Block Diagram/Ladder (FBD/LD).
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

Engineered for demanding automation tasks, the Mitsubishi PLC Controller Module FX5-32ET/DSS and FX5-32ET/ESS deliver exceptional control performance for the MELSEC iQ-F platform. These modules combine high-speed processing, extensive memory, and flexible programming to optimize machine and process control in industrial environments. With a refresh system for I/O control and support for direct access I/O (DX, DY), they ensure precise and responsive operation. The robust design includes a constant scan function (0.2 to 2000 ms) and fixed-cycle interrupts (1 to 60000 ms), making them ideal for time-critical applications. Whether you need high-speed logic or complex data handling, these modules provide the reliability and scalability required for modern automation systems.

Parameter	Specification
Control system	Stored-program repetitive operation
Input/output control system	Refresh system (Direct access input/output allowed by specification of direct access input/output [DX, DY])
Programming language	Ladder diagram (LD), structured text (ST), function block diagram/ladder language (FBD/LD)
Programming expansion function	Function block (FB), function (FUN), label programming (local/global)
Constant scan	0.2 to 2000 ms (can be set in 0.1 ms increments)
Fixed cycle interrupt	1 to 60000 ms (can be set in 1 ms increments)
Timer performance specifications	100 ms, 10 ms, 1 ms
No. of program executions	32
No. of FB files	16 (Up to 15 for user)
Execution type	Standby type, initial execution type, scan execution type, fixed-cycle execution type, event execution type
Interrupt type	Internal timer interrupt, input interruption, high-speed comparison match interrupt, interrupt from module
Instruction processing time LD X0	34 ns
Instruction processing time MOV D0 D1	34 ns
Memory Program capacity	64 k steps (128 kbytes, flash memory)
SD memory card	Memory card capacity (SD/SDHC memory card: Max. 4 Gbytes)
Device/label memory	120 kbytes
Data memory/standard ROM	5 Mbytes
Flash memory (Flash ROM) write count	Max. 20000 times
File storage capacity	1
Data memoryP: No. of program files FB: No. of FB files	P: 32, FB: 16
SD memory card	2 Gbytes: 511Q1, 4 Gbytes: 65534Q1
Clock function	Year, month, day, hour, minute, second, day of week (leap year automatic detection)
Precision	Monthly difference: ±45 sec at 25°C (typical value)
(1) No. of input/output points	256 points or less
(2) No. of remote I/O points	384 points or less
Total No. of points of (1) and (2)	512 points or less
Capacity for power failure retention	12 K words maximum

High-Speed Processing: LD and MOV instructions executed in 34 ns for rapid logic and data transfer.
Extensive Memory: 64 k steps program memory, 120 kbytes device/label memory, and 5 Mbytes data memory for complex applications.
Flexible Programming: Supports LD, ST, FBD/LD, FB, and label programming for diverse control strategies.
Robust Interrupt Handling: Internal timer, input, high-speed comparison match, and module interrupts ensure real-time response.
Scalable I/O: Up to 256 local I/O points and 384 remote I/O points for system expansion.
Reliable Power Failure Retention: Retains up to 12 K words of critical data during power loss.
SD Memory Card Support: Enables easy data logging and program storage up to 4 Gbytes.
