Mitsubishi L60ADIL8-CM Analog I/O Module

Series#: Mitsubishi

Product Details

MITSUBISHI IQ-L ANALOG I/O MODULE L60ADIL8-CM L60ADVL8-CM L60MD4-G-CM – A versatile combination of analog input, voltage input, and digital output modules for the MELSEC iQ-L series.
High-speed 80 µs/channel conversion rate for precision process control in industrial automation.
Supports 4 to 20 mA current input (L60ADIL8-CM) and 0 to 10 V voltage input (L60ADVL8-CM) with 16-bit resolution.
L60MD4-G-CM provides 4-point transistor sink outputs with surge suppression for reliable discrete control.
Robust isolation (500 VAC between I/O and power) ensures noise immunity in harsh factory environments.
Easy integration via iQ-L bus backplane with screw terminal connections for field wiring.
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

The MITSUBISHI IQ-L ANALOG I/O MODULE L60ADIL8-CM L60ADVL8-CM L60MD4-G-CM set is engineered for demanding automation tasks requiring mixed analog and digital I/O. The L60ADIL8-CM is an 8-channel isolated analog input module accepting 4–20 mA current signals, while the L60ADVL8-CM handles 0–10 V voltage inputs with 16-bit resolution. The L60MD4-G-CM adds 4-point transistor sink outputs for driving actuators or indicators. All modules feature high-speed conversion (80 µs/channel) and 500 VAC isolation, making them ideal for PLC-based systems in manufacturing, water treatment, and process industries. Below are the detailed technical specifications derived from the product series.

Parameter	L60ADIL8-CM (Current Input)	L60ADVL8-CM (Voltage Input)	L60MD4-G-CM (Digital Output)
Input/Output Type	Analog current input (4–20 mA)	Analog voltage input (0–10 V)	Transistor sink output (4 points)
Number of Channels	8 channels (isolated)	8 channels (isolated)	4 output points
Resolution	16-bit (0–20,000 counts)	16-bit (0–20,000 counts)	N/A
Conversion Speed	80 µs per channel	80 µs per channel	0.5 ms (ON/OFF response)
Accuracy	±0.1% of full scale (25°C)	±0.1% of full scale (25°C)	N/A
Isolation Voltage	500 VAC between I/O and power	500 VAC between I/O and power	500 VAC between output and power
Power Supply	24 VDC (via iQ-L bus)	24 VDC (via iQ-L bus)	24 VDC (via iQ-L bus)
Current Consumption	250 mA (5 VDC internal)	250 mA (5 VDC internal)	200 mA (5 VDC internal)
Operating Temperature	0 to 55°C	0 to 55°C	0 to 55°C
Storage Temperature	-25 to 75°C	-25 to 75°C	-25 to 75°C
Weight	Approx. 0.2 kg	Approx. 0.2 kg	Approx. 0.15 kg

L60ADIL8-CM Key Features: 8 isolated current inputs (4–20 mA) with 16-bit resolution; 80 µs/channel conversion; screw terminal wiring; supports offset/gain adjustment via software.
L60ADVL8-CM Key Features: 8 isolated voltage inputs (0–10 V) with 16-bit resolution; 80 µs/channel conversion; includes input filter for noise reduction; compatible with iQ-L bus.
L60MD4-G-CM Key Features: 4-point transistor sink outputs (0.5 A per point); surge suppression (zener diode); short-circuit protection; LED status indicators for each channel.
Common Specifications: All modules use 24 VDC bus power; 500 VAC isolation; operating humidity 5–95% non-condensing; vibration resistance up to 5.9 m/s² (10–57 Hz).
Certifications: CE, UL/cUL, and RoHS compliant; designed for industrial control cabinets with IP20 protection.
Application Notes: Ideal for temperature, pressure, and flow monitoring (analog) combined with relay or solenoid control (digital) in PLC-based systems.
