The Mitsubishi iQ-R series R08PCPU and R16PCPU represent the pinnacle of programmable controller performance, engineered for high-speed, reliable control in complex industrial environments. These CPU modules utilize a stored program cyclic operation method, ensuring deterministic execution of logic. With support for ladder diagrams, structured text, function block diagrams, and sequential function charts, the R08PCPU and R16PCPU offer unparalleled flexibility for system engineers. The I/O control mode employs a refresh system with direct access I/O capability (DX, DY) for real-time response. Both models feature a constant scan function adjustable from 0.5 ms to 2000 ms in 0.1 ms increments, maintaining consistent cycle times. The R08PCPU and R16PCPU are designed to handle up to 4096 I/O points, making them ideal for mid-to-large scale automation projects.
| Parameter |
R08PCPU |
R16PCPU |
| Control method |
Stored program cyclic operation |
| I/O control mode |
Refresh mode (Direct access I/O available via DX, DY) |
| Programming language |
Ladder diagram (LD), structured text (ST), function block diagram (FBD), sequential function chart (SFC) |
| Extended programming language |
Function block (FB), label programming (system/local/global) |
| Program execution type |
Initial, scan, fixed scan, interrupt, standby |
| Number of I/O points [X/Y] |
4096 |
4096 |
| Constant scan (ms) |
0.5…2000 (0.1 ms increments) |
0.5…2000 (0.1 ms increments) |
- High-Speed Processing: The R08PCPU and R16PCPU deliver fast scan cycles for time-critical applications, with constant scan support down to 0.5 ms.
- Flexible Programming: Engineers can leverage LD, ST, FBD, and SFC languages, plus FB and label programming for modular code.
- Direct I/O Access: Refresh mode with DX/DY instructions enables immediate I/O updates without waiting for the end of scan.
- Scalable Architecture: Both models support up to 4096 I/O points, easily expanding with iQ-R series modules.
- Reliable Operation: Stored program cyclic execution ensures predictable behavior in harsh industrial settings.
- Global Compatibility: 100% original and new units, ready for immediate shipment worldwide.
