The Mitsubishi iQ-R R16ENCPU and R32ENCPU are next-generation CPU modules designed for high-speed, high-capacity control in demanding automation environments. These units integrate Ethernet connectivity directly on the CPU, eliminating the need for separate communication modules and enabling streamlined data exchange with SCADA, HMI, and other networked devices. With robust processing power and a rich set of programming options, they are ideal for complex machinery, production lines, and process control applications where reliability and performance are paramount.
| Parameter |
R16ENCPU |
R32ENCPU |
| Control Method |
Stored program cyclic operation |
| I/O Control Mode |
Refresh mode (Direct access I/O available via DX, DY) |
| Programming Languages |
Ladder (LD), Structured Text (ST), Function Block Diagram (FBD), Sequential Function Chart (SFC) |
| Extended Programming |
Function Block (FB), Label Programming (System/Local/Global) |
| Program Execution Types |
Initial, Scan, Fixed Scan, Interrupt, Standby |
| Number of I/O Points [X/Y] (points) |
4096 |
4096 |
| Constant Scan (ms) |
0.5…2000 (0.1 ms increments) |
0.5…2000 (0.1 ms increments) |
- High-Speed Processing: The R16ENCPU and R32ENCPU deliver rapid scan cycles, ensuring real-time control for time-critical applications.
- Integrated Ethernet Port: Built-in Ethernet allows direct connection to industrial networks (e.g., CC-Link IE Field, Modbus TCP) without additional hardware.
- Large Memory Capacity: Ample program and data memory support complex logic and extensive tag databases.
- Robust Security Features: Password protection, access levels, and secure boot capabilities safeguard intellectual property and prevent unauthorized changes.
- Hot-Swappable SD Memory Card Slot: Enables easy program backup, data logging, and firmware updates without stopping the system.
- Comprehensive Diagnostics: Built-in error history, event logging, and LED indicators simplify troubleshooting and reduce downtime.
- Scalable Architecture: Compatible with the full iQ-R series of I/O, motion, and safety modules for customized system expansion.
