The ABB PM590-ARCNET-V14X AC500 CPU module is a cornerstone of the AC500 PLC family, designed for demanding distributed control applications. This unit features a powerful 32-bit processor and a generous 2 MB program memory, enabling complex logic sequences and data handling. With its built-in ARCNET interface, it seamlessly connects to high-speed deterministic networks, while serial and fieldbus ports provide versatile connectivity to I/O modules, drives, and HMI devices. The module's compact footprint (67.5 mm x 76 mm x 62 mm) and IP20 rating make it ideal for space-constrained control panels. It is engineered for long-term reliability in harsh industrial settings, with a wide operating temperature range and robust Flash EPROM storage for user data.
| Specification |
Details |
| Product Type |
Programmable Logic Controller (PLC) CPU Module |
| Model |
PM590-ARCNET-V14X AC500 |
| Processor |
32-bit RISC |
| Memory - User Program |
2048 kB (2 MB) |
| Memory - User Data |
2560 kB (2.5 MB) |
| Memory Type |
Flash EPROM |
| Communication Interfaces |
Serial (RS-232/485), Fieldbus (FBP), ARCNET |
| Display Type |
LCD (Status/Diagnostic) |
| Supply Voltage |
24 V DC |
| Power Consumption |
Typically 5 W |
| Degree of Protection |
IP20 |
| Operating Temperature |
0°C to +60°C |
| Storage Temperature |
-40°C to +70°C |
| Product Net Weight |
0.16 kg |
| Product Net Depth / Length |
62 mm |
| Product Net Height |
76 mm |
| Product Net Width |
67.5 mm |
| Gross Weight |
0.22 kg |
| Mounting |
DIN rail (35 mm) |
| Applicable Standard |
IEC 61131-2 |
| CE Marking |
Yes |
| RoHS Compliant |
Yes |
| eClass |
27-24-22-07 |
| UNSPSC |
32151705 |
| WEEE Category |
5. Small Equipment (No External Dimension More Than 50 cm) |
