Allen-Bradley 1757-FFLD2 Fieldbus Module

Series#: AllenBradley

Product Details

1757-FFLD2 ALLEN-BRADLEY – High-performance FOUNDATION Fieldbus Linking Device for seamless process automation integration.
Supports up to 2 FOUNDATION Fieldbus H1 segments for efficient device communication.
Redundant power and communication options ensure maximum system uptime and reliability.
Compatible with ControlLogix and PlantPAx systems for scalable distributed control.
Built-in diagnostics and LED indicators for quick fault detection and maintenance.
100% Genuine and New, rigorously inspected before international dispatch.

Specification

The 1757-FFLD2 ALLEN-BRADLEY is a FOUNDATION Fieldbus Linking Device designed to bridge H1 fieldbus segments with high-speed control networks in industrial process environments. This module acts as a central interface, enabling seamless data exchange between field instruments and controllers like ControlLogix. With support for two H1 segments, it reduces wiring complexity and enhances system flexibility. The 1757-FFLD2 features redundant power inputs and communication paths, ensuring robust operation in critical applications. Its compact form factor and hot-swappable design simplify installation and maintenance, while integrated diagnostics provide real-time segment health monitoring. Ideal for oil and gas, chemical, and pharmaceutical industries, this device meets IEC 61158 standards for interoperability and reliability.

Parameter	Specification
Model Number	1757-FFLD2
Product Type	FOUNDATION Fieldbus Linking Device
Supported Segments	2 H1 Segments (31.25 kbit/s each)
Communication Protocol	FOUNDATION Fieldbus H1 (IEC 61158 Type 1)
Network Interface	ControlNet or EtherNet/IP (via backplane)
Power Supply	24V DC nominal, redundant inputs
Power Consumption	Typical 10W, maximum 15W
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5% to 95% non-condensing
Dimensions (H x W x D)	Approx. 130 mm x 50 mm x 120 mm
Weight	Approx. 0.45 kg (1.0 lb)
Redundancy Support	Yes – Power and communication
Diagnostics	LED indicators for segment status, power, and fault
Certifications	CE, UL, ATEX (Zone 2), IECEx
Compatibility	ControlLogix 1756, PlantPAx, and RSLogix 5000
Wiring Termination	Removable screw terminals for fieldbus and power
Maximum Devices per Segment	32 field instruments (H1 standard)
Mounting	DIN rail or panel mount
Protection Class	IP20 (enclosed cabinet required)
