The Allen-Bradley 1756-TBSH is a high-performance backplane module engineered for the ControlLogix platform, serving as the backbone for real-time data exchange between processors, I/O modules, and communication interfaces. This module ensures deterministic communication with minimal jitter, supporting complex automation tasks in manufacturing, process control, and infrastructure applications. Its rugged design withstands harsh industrial conditions, including temperature extremes and vibration, while maintaining consistent throughput for up to 7 slots. The 1756-TBSH integrates seamlessly with standard ControlLogix chassis, enabling scalable system architectures without compromising signal quality.
| Parameter |
Specification |
| Model Number |
1756-TBSH |
| Product Type |
ControlLogix Chassis Backplane Module |
| Number of Slots Supported |
7 (Single Chassis) |
| Backplane Data Rate |
Up to 1 Gbps (Serial Backplane) |
| Communication Protocol |
ControlBus (Proprietary Allen-Bradley) |
| Power Consumption |
5.5 W (Typical), 7.0 W (Maximum) |
| Operating Temperature Range |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature Range |
-40°C to 85°C (-40°F to 185°F) |
| Relative Humidity |
5% to 95% Non-Condensing |
| Shock Resistance |
30 g, 11 ms Duration (Operational) |
| Vibration Resistance |
2 g, 10-500 Hz (Operational) |
| Isolation Voltage |
1500 V AC (Backplane to Ground) |
| Connector Type |
DIN 41612 (Male, 96-Pin) |
| Dimensions (H x W x D) |
Approx. 130 mm x 45 mm x 100 mm (5.12 in x 1.77 in x 3.94 in) |
| Weight |
0.25 kg (0.55 lbs) |
| Compatible Chassis |
1756-A7, 1756-A10, 1756-A13, 1756-A17 (Standard Models) |
| Certifications |
CE, UL, CSA, ATEX (Zone 2), IECEx |
| RoHS Compliance |
Yes |
| Warranty |
1 Year (Standard), Extended Options Available |
