1756-CFM Allen-Bradley

Series#: AllenBradley

Product Details

1756-CFM – A critical Allen-Bradley ControlLogix chassis filler module for empty slot protection and system integrity.
Provides mechanical closure and EMC shielding for unused I/O or communication slots in 1756 chassis.
Ensures proper airflow management and dust prevention within the ControlLogix backplane environment.
Easy plug-and-play installation – no configuration, wiring, or software required.
Compatible with all standard 1756-series chassis (4, 7, 10, 13, 17-slot versions).
Essential for maintaining system certification and reducing electromagnetic interference (EMI).
100% Brand New & Original, securely packed and ready for reliable global shipping.

Specification

The Allen-Bradley 1756-CFM ControlLogix Chassis Filler Module is a passive, non-electronic component designed to occupy unused slots within a 1756 chassis. In industrial automation systems, empty slots can disrupt airflow, compromise EMC shielding, and collect debris. The 1756-CFM resolves these issues by providing a seamless mechanical barrier that maintains the chassis’s thermal profile and electromagnetic compatibility. It is a mandatory accessory for any ControlLogix system where slot utilization is not 100%, ensuring compliance with Rockwell Automation's design standards. The module is constructed from high-grade, flame-retardant plastic and features a robust latch mechanism for secure retention. No firmware, power supply, or communication cabling is needed – simply insert it into any open slot to complete the chassis assembly. This filler module is ideal for system integrators and maintenance teams seeking to preserve reliability and reduce downtime in critical process control applications.

Parameter	Specification
Product Type	Chassis Filler Module
Series	ControlLogix
Model Number	1756-CFM
Compatible Chassis	All 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17
Material	Flame-retardant thermoplastic (UL 94 V-0 rated)
Weight	Approx. 0.05 kg (0.11 lb)
Dimensions (H x W x D)	144 mm x 36 mm x 128 mm (5.67 in x 1.42 in x 5.04 in)
Operating Temperature	0°C to +60°C (32°F to 140°F)
Storage Temperature	-40°C to +85°C (-40°F to 185°F)
Relative Humidity	5% to 95% non-condensing
Shock Rating	30 g operational, 50 g non-operational
Vibration Rating	2 g Standard Models 10–500 Hz
EMC Shielding	Yes – provides continuous ground path for chassis
Airflow Management	Yes – prevents bypass airflow through empty slots
Mounting	Snap-fit into chassis slot; no tools required
Electrical Connection	None (passive component)
Certifications	CE, cULus, ATEX (when used in certified system)
